Product Description: Siemens 6AV2124-0QC02-0AX1 SIMATIC HMI KTP 600 Basic

The Siemens 6AV2124-0QC02-0AX1 is a 7-inch touchscreen from the SIMATIC HMI series, specifically the KTP 600 Basic model. This panel is designed for industrial automation, offering a reliable and cost-effective solution for controlling and monitoring machines and processes. The HMI panel features a high-resolution TFT display for clear visualization of data and a user- friendly touchscreen interface for efficient operation. It supports integration with Siemens PLCs via PROFINET and provides diagnostic features to ensure smooth system operation.

Key Features

• Display Size: 7-inch TFT color touchscreen
• Display Type: High-resolution TFT for clear and easy visualization of machine parameters
• User Interface: Touchscreen interface for intuitive operation and control
• Communication Protocols: Supports communication with Siemens PLCs using PROFINET and other industrial networks
• Programming: Configurable with Siemens WinCC flexible or TIA Portal software for easy integration and setup
• Mounting: Panel mount for integration into control cabinets or machine enclosures
• Operating Temperature Range: Suitable for industrial environments with an operating temperature range of 0°C to +50°C
• Diagnostic Features: Built-in diagnostics for monitoring system status and fault detection

Technical Specifications

• Product Type: Human Machine Interface (HMI)
• Part Number: 6AV2124-0QC02-0AX1
• Display Size: 7-inch
• Display Type: TFT, high-resolution
• Touch Interface: Yes, touch-screen interface
• Communication Protocols: PROFINET, Industrial Ethernet
• Operating Temperature Range: 0°C to +50°C
• Mounting: Panel mount
• Dimensions (W x H x D): 178 mm x 150 mm x 43 mm
• Weight: Approx. 0.6 kg

Application Areas

• Factory Automation: Ideal for controlling and monitoring machines and automated production lines in industrial environments.
• Process Control: Used in process industries such as food and beverage, chemical, and pharmaceuticals for real-time monitoring and control of processes.
• Building Automation: Suitable for controlling building systems such as HVAC, lighting, and security in building management systems.
• Machine Control: Provides operators with an easy-to-use interface for controlling machines and automated systems.

Advantages

• Compact Design: The 7-inch size provides a balance between usability and space efficiency for machine and control panel integration.
• High-Resolution Display: The TFT display ensures clear and readable data even in challenging industrial lighting conditions.
• Flexible Integration: Supports a wide range of communication protocols, allowing seamless integration with Siemens PLCs and other automation devices.
• Reliable Diagnostics: Built-in diagnostic functions help identify faults quickly, improving system uptime and minimizing maintenance.
