Product Description: Siemens 6AV6545-0BC15-2AX0

The Siemens 6AV6545-0BC15-2AX0 is a 5.7-inch color touchscreen HMI panel from the SIMATIC HMI Basic Panels series, specifically designed for industrial automation applications. It combines a high-resolution color display with integrated function keys, providing a reliable and efficient interface for machine and process control. The MP 177B panel supports various communication protocols, including PROFIBUS and MPI, allowing for easy integration into Siemens automation systems. Its compact design and intuitive touch interface make it ideal for controlling and monitoring industrial processes in space- constrained environments.

Key Features

• Display: 5.7" TFT color touchscreen with 320 × 240 resolution and 65,536 colors
• Operation: Touchscreen interface with 6 integrated function keys for user interaction
• Communication Protocols: PROFIBUS and MPI interfaces for seamless integration with Siemens automation systems
• User Memory: 1 MB for storing configuration and runtime data
• Power Supply: 24 V DC with low power consumption
• Protection Class: IP65 front protection, ensuring durability in industrial environments
• Mounting: Panel mounting for space-efficient installation

Technical Specifications

• Display Type: TFT color touchscreen
• Screen Size: 5.7 inches
• Resolution: 320 × 240 pixels
• Number of Colors: 65,536
• Operation Type: Touchscreen with 6 function keys
• Memory: 1 MB user memory
• Interfaces: PROFIBUS, MPI
• Power Supply: 24 V DC
• Power Consumption: Low power consumption
• Protection Class: IP65 (front)
• Dimensions (W × H × D): 180 mm × 140 mm × 50 mm
• Weight: 1.2 kg

Application Areas

• Operator interface for machine and process control
• Monitoring and controlling industrial machinery
• Suitable for use in compact control panels and limited spaces
• Integration into Siemens automation systems via PROFIBUS and MPI

Advantages

• Compact design and user-friendly touch interface ideal for space-constrained applications
• Integrated function keys provide efficient control and operation
• High-resolution color display enhances process visualization
• IP65 front protection ensures durability and reliability in harsh industrial environments
