Product Description: Siemens 6AV6545-0BA15-2AX0

The Siemens 6AV6545-0BA15-2AX0 is a 10.4-inch HMI touch panel from the SIMATIC MP 270B series, designed for demanding machine-level and process-level visualization tasks. Featuring a TFT color touchscreen, this multi panel supports a wide range of HMI functions including process display, alarm handling, recipe management, and communication with multiple PLCs. It operates on Windows CE, enabling flexible integration in automation environments. The MP 270B offers high-resolution display, multiple communication ports, and is fully programmable via WinCC flexible or ProTool, making it a reliable operator interface for industrial applications requiring robust functionality and long-term availability.

Key Features

• 10.4” Color TFT Display: 640 × 480 pixels resolution, 256 colors
• Touchscreen Operation: Analog resistive panel for intuitive operator interaction
• Windows CE Platform: Enables embedded HMI functions and flexible runtime behavior
• Integrated Communication: Supports MPI/PROFIBUS DP, RS232, and Ethernet (via optional modules)
• Extensive Runtime Functions: Includes alarms, trending, recipe handling, and user management
• Panel-Mounted IP65 Front: Designed for harsh industrial environments

Technical Specifications

• Product Type: HMI Touch Panel
• Part Number: 6AV6545-0BA15-2AX0
• Series: SIMATIC MP 270B
• Display Size: 10.4" TFT
• Resolution: 640 × 480 pixels (VGA)
• Display Colors: 256 (8-bit)
• Touch Interface: Analog resistive touchscreen
• Operating System: Windows CE
• Runtime Software: WinCC flexible RT or ProTool Runtime
• Interfaces: 1 × MPI/DP, 1 × RS232, Ethernet (optional module)
• Memory: Flash + RAM (expandable via CF card)
• Power Supply: 24 V DC
• Protection (Front): IP65
• Protection (Rear): IP20
• Mounting: Panel-mounted
• Operating Temperature: 0°C to +50°C
• Dimensions (W × H × D): Approx. 340 × 275 × 60 mm
• Weight: Approx. 3.8 kg

Application Areas

• Machine-Level Visualization: Control interface for packaging, CNC, and processing machines
• Production Line HMIs: Connects to S7-300/S7-400 PLCs for real-time monitoring and control
• Process Automation: Suitable for tank farms, water treatment, and food processing lines
• Legacy Systems Modernization: Integrates into existing ProTool or WinCC-based HMI setups

Advantages

• Reliable Operation: Proven HMI platform for continuous industrial use
• Versatile Communication: Supports multiple PLCs and protocols
• Expandable Storage: CompactFlash support for recipes, logs, and updates
• Easy to Configure: Engineering via WinCC flexible or ProTool for fast commissioning
• Durable and Industrial-Grade: Robust panel designed for factory-floor environments
