HMI Device | Siemens | 6AV6542-0BB15-2AX0 SMART PLC Module 6AV6542-0BB15-2AX0

Product Description: Siemens 6AV6542-0BB15-2AX0

The Siemens 6AV6542-0BB15-2AX0 is an MP370 HMI from the SIMATIC Multi Panel series, featuring a 12.1-inch TFT color touchscreen for versatile operator control and visualization. It supports multiple communication protocols, including MPI, PROFIBUS DP, and Industrial Ethernet (with optional modules), allowing seamless integration into a variety of Siemens automation systems. With its high-resolution display and robust performance, it is ideal for complex applications in industrial and process environments. Configuration is carried out using WinCC flexible or ProTool.

Key Features

• Display: 12.1" TFT color, 800 × 600 resolution, 256 colors
• Operation: Analog-resistive touchscreen
• Interfaces: MPI, PROFIBUS DP, RS-232, RS-422/485, USB, optional Ethernet
• Memory: Flash and RAM for runtime and project data
• Mounting: Panel mounting with IP65-rated front face
• Configuration Software: WinCC flexible or ProTool

Technical Specifications

• System Series: SIMATIC HMI MP 370
• Module Type: Multi Panel (Touchscreen)
• Display Size: 12.1 inches
• Display Resolution: 800 × 600 pixels
• Number of Colors: 256
• Touchscreen Type: Analog-resistive
• Communication Interfaces: MPI, PROFIBUS DP, RS-232/422/485, USB, optional Ethernet
• Power Supply Voltage: 24 V DC (19.2 – 28.8 V DC)
• Power Consumption: Approx. 25 W
• Operating Temperature Range: 0 °C to +50 °C
• Dimensions (W × H × D): Approx. 340 mm × 270 mm × 65 mm
• Protection Class (Front/Rear): IP65 / IP20
• Certifications: CE, cULus, RCM

Application Areas

• High-end machine-level operator interface
• Process monitoring and control in industrial automation
• Multi-protocol connectivity for legacy and modern systems
• Advanced HMI for packaging, food processing, and chemical plants

Advantages

• Large, high-resolution color touchscreen for detailed process visualization
• Multiprotocol communication for broad system compatibility
• Rugged design suitable for demanding industrial conditions
• Expandable and configurable to meet complex HMI requirements
