Allen-Bradley | 22A-D4P0N104|PowerFlex 4 (22A Series)

Product Description: Allen-Bradley 22A-D4P0N104 PowerFlex 4 AC drive

The Allen-Bradley 22A-D4P0N104 is a PowerFlex 4 AC drive designed for simple, cost-effective variable speed control of 3-phase induction motors. It supports a 3-phase 380–480V AC input and delivers up to 4.0 A output current, making it suitable for motors rated at 1.5 kW (2 HP). With its compact design, integral keypad, and intuitive programming, this drive is an ideal choice for basic motor control applications in industrial and OEM settings.

Key Features

• Input Voltage: 3-phase, 380–480V AC, 50/60 Hz
• Output Power: 1.5 kW (2 HP)
• Output Current: 4.0 A
• Control Mode: Volts/Hertz (V/Hz)
• Built-in keypad with 4-digit LED display and local control buttons
• RS-485 Modbus RTU communication (standard)
• Compact IP20 open-type housing for panel-mounted installation
• DIN rail or panel mounting options
• Programmable I/O for flexibility in integration

Technical Specifications

• Voltage Class: 480V
• Frequency Range: 0–400 Hz
• Motor Control: V/Hz (Volts per Hertz)
• I/O:
  • 4 digital inputs
• Communication: RS-485 (Modbus RTU)
• Ambient Operating Temperature: -10°C to 50°C (up to 60°C with derating)
• Enclosure: IP20 (Open Type)
• Dimensions (HxWxD): Approx. 174 x 72 x 152 mm
• Certifications: UL Listed, CE, cUL, RoHS, Class I Div 2

Application Areas

• Basic fan and pump control
• Light-duty conveyors and mixers
• Machine tools and packaging machinery
• HVAC and small OEM equipment
• General-purpose industrial motor control

Advantages

• Cost- effective and reliable for simple speed control
• Compact design reduces panel space requirements
• Built-in keypad simplifies commissioning and operation
• RS-485 support enables easy connection to HMI or PLC
• Ideal for applications not requiring advanced vector control
