Allen-Bradley | 22A-B012N104 |PowerFlex 4

Product Description: Allen-Bradley 22A-B012N104

The Allen-Bradley 22A-B012N104 is a compact, general-purpose AC drive from the PowerFlex 4 series, designed for controlling three-phase induction motors in a wide range of industrial and commercial applications. This variable frequency drive (VFD) delivers dependable motor control, energy efficiency, and flexible integration in compact installations. With a power rating of 2 HP (1.5 kW) and an output current of 12.0 A, this drive supports input voltages from 480V AC, 3-phase, and features a built-in keypad for parameter configuration and monitoring. The 22A-B012N104 is engineered for simplicity and reliability, making it ideal for standalone machines or simple system control.

Product Type

• Variable Frequency Drive (VFD)
• Series: PowerFlex 4
• Application Category: General-purpose motor control

Key Features

• Power Rating: 2 HP (1.5 kW)
• Output Current: 12.0 A
• Input Voltage: 3-phase, 380–480V AC
• Input Frequency: 50/60 Hz
• Motor Control: Volts/Hertz (V/Hz) control
• Adjustable Accel/Decel Times: 0–600 seconds
• Integrated keypad with LED display for easy configuration
• 5 digital inputs, 1 analog input, and 1 relay output
• Built-in RS-485 (Modbus RTU) for communication
• DIN rail or panel mountable
• UL, CE, CSA, C-Tick, and RoHS compliant
• Protection Features: Overload, short-circuit, ground fault, overvoltage, undervoltage, and stall protection

Technical Specifications

• Enclosure Type: Open type (IP20)
• Carrier Frequency: Selectable (2–16 kHz)
• Ambient Operating Temperature: -10°C to +50°C (no derating)
• Control Method: Scalar (V/Hz) control
• Display: LED 4-digit display
• Mounting Options: Panel mount or DIN rail
• Dimensions (HxWxD): Approx. 152 mm x 85 mm x 152 mm
• Weight: Approx. 1.5 kg

Application Areas

• Conveyors and material handling
• Fans and blowers
• Pumps
• Packaging and labeling equipment
• Small machinery and OEM applications
• HVAC systems

Advantages

• Compact design for space-saving installations
• Easy-to-use interface for quick setup and monitoring
• Reliable motor control with essential protection features
• Suitable for a wide range of simple variable-speed applications
• Network-ready with RS-485 built-in communication
