Allen-Bradley | 22A-D8P7N104 | PowerFlex 4

Product Description: Allen-Bradley 22A-D8P7N104

The Allen-Bradley 22A-D8P7N104 is a compact PowerFlex 4 AC drive designed for cost-effective motor speed control in general-purpose applications. With a 2.2 kW (3 HP) power rating and 3-phase 380–480V AC input, this drive is ideal for basic variable-speed applications. It supports V/Hz control, features integral keypad programming, and includes RS-485 (DSI) communication for simple integration.

Key Features

• 2.2 kW (3 HP) motor power rating
• 3-phase 380–480V AC input
• Output current: 8.7 A
• V/Hz (Volts per Hertz) control mode
• Integrated RS-485 (DSI) serial communication
• Built-in keypad with LED display
• Programmable digital and analog I/O
• Compact size with DIN rail or panel mounting
• IP20 NEMA Open Type enclosure

Technical Specifications

• Input Voltage: 3-phase, 380–480V AC
• Output Voltage: 0–480V AC
• Output Current: 8.7 A
• Frequency Range: 0–400 Hz
• Control Method: V/Hz
• Communication: RS-485 (DSI)
• Enclosure Type: IP20 / NEMA Open Type
• Programming Interface: Integrated keypad
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Mounting: DIN rail or panel mount

Application Areas

• Small conveyors
• Fans and blowers
• Light-duty pumps
• Machine tools
• Basic OEM machinery

Advantages

• Economical solution for basic motor control
• Quick installation and easy setup via onboard keypad
• Integrated communication simplifies system integration
• Compact design saves panel space
• Reliable performance for light-duty industrial tasks
