PowerFlex 4 | Allen-Bradley | 22A-B012N104 /A Powerflex 4 AC Drive

Product Description: Allen-Bradley 22A-B012N104

The Allen-Bradley 22A-B012N104 is a PowerFlex 4 AC drive designed for compact, cost-effective motor speed control in general- purpose applications. Rated at 3.7 kW (5 HP) with a 3-phase 200–240V AC input, this drive offers reliable performance with V/Hz control, integrated RS-485 (DSI) communication, and intuitive keypad programming. Its small footprint and flexible mounting make it ideal for OEM and light-duty industrial use.

Key Features

• 3.7 kW (5 HP) motor rating
• 3-phase, 200–240V AC input
• Output current: 12 A
• Supports V/Hz (Volts per Hertz) control
• Integrated RS-485 (DSI) communication
• Built-in LED keypad for programming and monitoring
• Programmable analog and digital I/O
• Compact design with DIN rail or panel mounting
• IP20 / NEMA Open Type enclosure

Technical Specifications

• Input Voltage: 3-phase, 200–240V AC
• Output Voltage: 0–240V AC
• Output Current: 12 A
• Frequency Range: 0–400 Hz
• Control Mode: V/Hz
• Communication: RS-485 (DSI)
• Enclosure Rating: IP20 / NEMA Open Type
• Programming Interface: Built-in LED keypad
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Mounting: DIN rail or panel mount

Application Areas

• Fans and pumps
• Light-duty conveyors
• HVAC systems
• OEM equipment requiring compact motor control
• General-purpose machinery in industrial settings

Advantages

• Compact and cost-effective design for small motor applications
• Easy setup via onboard keypad
• Integrated serial communication for flexible system integration
• Energy-efficient control with basic configuration
• Reliable and durable performance in light industrial environments
