HMI Device | Siemens | 6AV3607-1JC20-0AX1 6AV3 607-1JC20-0AX1 S7 M7 OP7/DP Operator Panel

Product Description: Siemens 6AV3607-1JC20-0AX1

The Siemens 6AV3607-1JC20-0AX1 is a TP1200 Comfort Panel from the SIMATIC HMI Comfort Panels series, featuring a 12-inch TFT color display and providing a high-performance human-machine interface for industrial automation systems. This panel is designed to provide easy and efficient control and visualization of machines and processes. With its high- resolution touchscreen and PROFINET communication, the 6AV3607-1JC20-0AX1 seamlessly integrates with Siemens S7-1200 and S7-1500 PLCs. Built for industrial environments, the TP1200 Comfort panel is equipped with an IP65-rated front for protection against dust and water, making it suitable for challenging conditions. It supports both touchscreen input and function keys, offering flexibility for operators in various industrial environments.

Key Features

• Display: 12" TFT color display with 1280 x 800 pixels resolution, providing clear and vibrant visuals for process monitoring.
• User Input: Touchscreen interface with function keys for intuitive operation and enhanced usability, including glove-friendly interaction.
• Communication: PROFINET interface for fast and reliable communication with Siemens PLC systems.
• Front Protection: IP65 rating ensures the panel is protected against dust and water in industrial environments.
• Memory: 12 MB of user memory to store projects, configuration, and data.
• Software Support: Configured and programmed using TIA Portal or WinCC Comfort, enabling easy setup and management.
• Multi-language Support: Allows for easy adaptation to various global markets with multilingual interfaces.

Technical Specifications

• Display Size: 12" TFT Color Display
• Resolution: 1280 x 800 pixels (WXGA)
• Touch Interface: Resistive touchscreen, glove-compatible
• Communication Interface: PROFINET (RJ45 Ethernet)
• Protection Class: IP65 (front panel)
• User Memory: 12 MB
• Power Supply: 24 V DC
• Operating Temperature: 0°C to +50°C
• Mounting: Panel mount (flush installation)
• Software Compatibility: TIA Portal, WinCC Comfort

Application Areas

• Machine Control: Used for controlling and visualizing machines such as conveyors, robotic systems, and packaging machines.
• Process Control: Ideal for industries like chemicals, food processing, pharmaceuticals, and more, providing real-time data visualization and control.
• Energy Management: Provides visibility into energy systems, enabling efficient control and monitoring of energy usage.
• Building Automation: Used for HVAC, lighting control, and other building management systems requiring easy monitoring and control.

Advantages

• High-Resolution Display: Provides a crisp and clear interface for improved operator interaction.
• Seamless Integration: Compatible with Siemens PLCs via PROFINET, offering fast and reliable communication.
• Durability: IP65-rated front panel ensures the panel can withstand industrial conditions, including dust and moisture.
• User-Friendly: Touchscreen interface and function keys allow for easy, flexible operation.
• Multi-language Support: Easily configurable for global deployment with support for multiple languages.
