PLC | Siemens | 6ES7 341-1CH02-0AE0 6ES7341-1CH02-0AE0 SIMATIC S7-300 CP 341

Product Description: 6ES7341-1CH02-0AE0

The 6ES7341-1CH02-0AE0 is an 8-channel digital transistor-output module for the SIMATIC S7-300 PLC family. In a 40 mm-wide SM 341 form-factor, it delivers eight isolated 24 V DC sinking outputs (PNP- compatible), each rated up to 0.5 A. The “High Feature” design offers per- channel diagnostics (short-circuit, overload, wire-break), configurable output behavior, and status LEDs. Plug-in mounting on the S7-300 backplane provides power and data without additional wiring, making it ideal for compact control systems requiring reliable actuator switching.

Key Features

• 8 transistor (sinking) outputs, 24 V DC, 0.5 A per channel
• Channel diagnostics: short- circuit, overload, wire-break detection
• Configurable switching behavior and diagnostic thresholds via STEP 7/TIA Portal
• Status LEDs for each output plus module status indicators
• 40 mm module width maximizes I/O density
• Hot-swap support in redundant or safety-rated racks

Technical Specifications

• Number of Outputs: 8
• Output Type: Transistor (sinking), 24 V DC
• Rated Load Current: 0.5 A per channel
• Total Module Load Current: ≤ 4 A
• Diagnostics: Short- circuit, overload, wire-break
• Switching Frequency: Up to 1 kHz (resistive load)
• Isolation: 500 V DC channel-to-backplane
• Power Consumption: 0.3 W (logic) + 2 W (field)
• Module Width: 40 mm
• Mounting: Plug-in on S7-300 rack backplane
• Operating Temperature: 0 … +60 °C
• Protection Class: IP20 (cabinet installation)
• Weight: ≈ 200 g

Application Areas

• Actuating solenoid valves, indicator lamps, and small DC motors
• Conveyor, packaging, and material-handling machinery
• Building automation relay drives and alarm outputs
• OEM systems requiring compact, high- feature digital outputs

Advantages

• Integrated diagnostics speed fault localization and reduce downtime
• High-feature filtering and parameterization enhance noise immunity
• Slim 40 mm design allows dense I/O in limited rack space
• Hot-swap capability enables maintenance without system shutdown
• Fully supported in STEP 7 and TIA Portal for seamless engineering and diagnostics
