Product Description: Siemens 6AV6647-0AF11-3AX0

The Siemens 6AV6647-0AF11-3AX0 is a TP177B HMI panel from the SIMATIC HMI TP 177B series. It features a 6-inch STN color display and analog-resistive touchscreen operation. With support for both MPI and PROFIBUS DP communication, this panel is ideal for compact to mid-range automation solutions. It enables clear visualization and reliable operator interaction for various machine-level applications and is configured via WinCC flexible 2005 or 2008.

Key Features

• Display: 6" STN color display, 320 × 240 resolution, 256 colors
• Operation: Analog-resistive touchscreen
• Interfaces: MPI/PROFIBUS DP, RS-485, 1 × USB for data transfer or printer connection
• Memory: Integrated configuration and runtime memory
• Mounting: Panel mounting with IP65-rated front face
• Configuration Software: WinCC flexible 2005/2008

Technical Specifications

• System Series: SIMATIC HMI TP 177B
• Module Type: Touch Panel (Color)
• Display Size: 6 inches
• Display Resolution: 320 × 240 pixels
• Display Type: STN color (256 colors)
• Touchscreen Type: Analog-resistive
• Communication Interfaces: MPI/PROFIBUS DP, RS-485, USB
• Power Supply Voltage: 24 V DC (19.2 – 28.8 V DC)
• Power Consumption: Approx. 7 W
• Operating Temperature Range: 0 °C to +50 °C
• Dimensions (W × H × D): 212 mm × 156 mm × 38 mm
• Protection Class (Front/Rear): IP65 / IP20
• Certifications: CE, cULus, RCM

Application Areas

• Operator interface for small and mid-size machines
• Visualization and monitoring in discrete automation systems
• Integration with S7-300/400 PLCs via MPI or PROFIBUS DP
• Compact machine control panels requiring touchscreen operation

Advantages

• Enhanced visibility with color display and touchscreen input
• Multiple communication options for system flexibility
• Space-saving and durable industrial design
• Simple configuration with WinCC flexible
