HMI Device | Siemens | 6AV6643-0BA01-1AX0 SMART PLC Module 6AV6643-0BA01-1AX0

Product Description: Siemens 6AV6643-0BA01-1AX0

The Siemens 6AV6643-0BA01-1AX0 is a KTP700 Comfort Panel, part of the SIMATIC HMI Comfort Panels series. It features a 7-inch TFT display, providing clear and intuitive visualization for machine and process control applications. This model combines a touchscreen interface with 6 function keys, offering a flexible user interface for industrial automation systems. The KTP700 Comfort Panel is equipped with an integrated PROFINET interface, allowing easy integration with Siemens S7-1200, S7-1500, S7-300, and S7-400 PLCs. It is designed for environments requiring high performance, with IP65-rated protection for the front panel, ensuring reliability in industrial conditions such as dust and moisture exposure.

Key Features

• Display Size: 7-inch TFT color display with 800 x 480 pixels resolution for clear visuals.
• User Input: Touchscreen interface with 6 physical function keys for versatile user input, including glove-friendly operation.
• Communication Interface: PROFINET (Ethernet) for fast and reliable data exchange with Siemens PLCs.
• Front Protection: IP65 rating, suitable for use in harsh industrial environments.
• Memory: 12 MB of user memory to store projects and configurations.
• Power Supply: Operates on 24 V DC, commonly used in industrial automation.
• Software Compatibility: Configured and programmed with TIA Portal and WinCC Comfort.

Technical Specifications

• Display Size: 7" TFT Color Display
• Resolution: 800 x 480 pixels (WVGA)
• Touch Interface: Resistive touchscreen
• Communication Interface: PROFINET (RJ45 Ethernet)
• Front Protection: IP65
• Power Supply: 24 V DC
• Memory: 12 MB User Memory
• Mounting: Panel mounting (flush installation)
• Operating Temperature: 0°C to +50°C

Application Areas

• Machine Control: Ideal for controlling and monitoring machinery in automation systems like conveyors, packaging machines, and robotics.
• Process Control: Suitable for visualizing and controlling processes in industries such as chemicals, pharmaceuticals, and food production.
• Energy Management: Provides real-time monitoring and control of energy- consuming systems such as HVAC, pumps, and motors.
• Building Automation: Used in building systems for the management of heating, ventilation, lighting, and security systems.

Advantages

• High- Resolution Display: Provides clear, high-quality visuals for real-time monitoring and control.
• Flexible User Interface: Supports both touchscreen and physical function keys, suitable for various industrial environments.
• Seamless Integration: Fully compatible with Siemens PROFINET-based PLC systems for fast and efficient communication.
• Durability: The IP65-rated front panel ensures protection against harsh conditions such as dust and water exposure.
• Easy Configuration: Simple configuration through TIA Portal for easy integration into existing automation systems.
