HMI Device | Siemens | 6AV6644-0AC01-2AX0 MP377 19" TOUCH PANEL 6AV6 644-0AC01-2AX0

Product Description: Siemens 6AV6644-0AC01-2AX0 (KTP900 Basic)

The Siemens 6AV6644-0AC01-2AX0 is a HMI (Human-Machine Interface) panel from the SIMATIC HMI Basic series, designed for use in industrial automation systems. With a 9-inch TFT display, the KTP900 Basic offers both touch and key operation for user interaction. It supports PROFINET communication, enabling seamless integration into industrial automation systems. The HMI is designed for environments where reliable, clear, and easy- to-use operator interfaces are required, providing intuitive control and monitoring of industrial processes.

Key Features

• Display: 9-inch TFT display with 65,536 colors and 800 × 480 resolution
• Operation: Touchscreen (analog- resistive) and 8 function keys
• Interfaces: PROFINET for seamless communication with PLCs and other devices
• Memory: 8 MB user memory
• Mounting: Panel mounting with IP65 front protection and IP20 rear protection
• Power Supply: 24 V DC (19.2–28.8 V DC permissible range)
• Mounting Type: Suitable for panel mounting

Technical Specifications

• Display Size: 9 inches
• Display Resolution: 800 × 480 pixels
• Number of Colors: 65,536
• Touchscreen Type: Analog- resistive
• Function Keys: 8
• Communication Interface: PROFINET
• User Memory: 8 MB
• Power Supply: 24 V DC (19.2–28.8 V DC)
• Mounting Protection: IP65 (front), IP20 (rear)
• Operating Temperature Range: 0 °C to +50 °C
• Dimensions (W × H × D): Approx. 224 mm × 164 mm × 36 mm
• Certifications: CE, UL, cULus, RoHS

Application Areas

• Operator interface for industrial automation systems
• Control and monitoring of processes in manufacturing, production, and assembly lines
• HMI integration in applications such as machinery control, material handling, and packaging
• Suitable for industrial environments with robust user interfaces

Advantages

• High-resolution 9-inch display for clear visualization of processes
• Easy integration into PROFINET-based automation systems
• Flexible user interaction with touch and key operation
• Durable design with IP65-rated front for protection against dust and water
