HMI Device | Siemens | 6AV6647-0AE11-3AX0 6AV6 647-0AE11-3AX0 SIMATIC HMI KTP1000

Product Description: Siemens 6AV6647-0AE11-3AX0

The Siemens 6AV6647-0AE11-3AX0 is a TP177A operator panel from the SIMATIC HMI series, equipped with a 6-inch monochrome STN display and analog-resistive touchscreen. It supports basic HMI functionality and is ideal for small to mid-range automation tasks. Communication is handled via MPI/PROFIBUS DP, allowing easy integration with Siemens S7-300 and S7-400 controllers. Configuration is performed using WinCC flexible 2005 or 2008.

Key Features

• Display: 6" STN monochrome, 4 grayscale levels, 320 × 240 resolution
• Operation: Analog-resistive touchscreen
• Interfaces: MPI/PROFIBUS DP, RS-485, 1 × USB
• Memory: Integrated project memory and runtime software
• Mounting: Panel mounting with IP65 front protection
• Configuration Software: WinCC flexible 2005/2008

Technical Specifications

• System Series: SIMATIC HMI TP 177A
• Module Type: Touch Panel (Monochrome)
• Display Size: 6 inches
• Display Resolution: 320 × 240 pixels
• Display Type: STN, monochrome (4 grayscales)
• Touchscreen Type: Analog-resistive
• Communication Interfaces: MPI/PROFIBUS DP, RS-485, USB
• Power Supply Voltage: 24 V DC (19.2 – 28.8 V DC)
• Power Consumption: Approx. 5 W
• Operating Temperature Range: 0 °C to +50 °C
• Dimensions (W × H × D): 212 mm × 156 mm × 38 mm
• Protection Class (Front/Rear): IP65 / IP20
• Certifications: CE, cULus, RCM

Application Areas

• Basic operator interface for small machines and equipment
• Monitoring and control of discrete processes
• Integration with S7-300/S7-400 systems via MPI or PROFIBUS
• Simple HMI solutions in space-constrained control panels

Advantages

• Cost-effective HMI solution for basic automation needs
• Compact design with durable front protection
• Easy configuration via WinCC flexible
• Reliable communication with Siemens controllers
