HMI Device | Siemens | 6AV6640-0CA11-0AX1 SIMATIC HMI TP900 6AV6 640-0CA11-0AX1

Product Description: Siemens 6AV6640-0CA11-0AX1

The Siemens 6AV6640-0CA11-0AX1 is a 10.4-inch multi-panel from the SIMATIC MP 277 series, featuring a bright TFT color display with 65 536 colors and a resolution of 640 × 480 pixels. Running Windows CE 5.0, it provides a stable runtime for operator interfaces in demanding industrial environments. The MP 277 supports both touch operation and 16 programmable function keys, and integrates via MPI, PROFIBUS DP or USS, making it suitable for versatile control applications.

Key Features

• Display: 10.4" TFT color, 640 × 480 pixels, 65 536 colors
• Operation: Analog-resistive touchscreen plus 16 programmable function keys
• Operating System: Windows CE 5.0 for reliable performance
• Memory: 8 MB configuration memory, 1 MB recipe memory
• Software Support: Configurable with WinCC flexible 2007 (TIA Portal compatible)
• Interfaces: 1 × MPI/PROFIBUS DP/USS, 1 × RS-232, 1 × USB, CF card slot
• Protection Class: IP65 front; IP20 rear
• Power Supply: 24 V DC (19.2 … 28.8 V DC)

Technical Specifications

• Screen Size: 10.4 inches
• Resolution: 640 × 480 pixels
• Colors: 65 536
• Touch Technology: Analog-resistive
• Function Keys: 16 programmable
• Configuration Memory: 8 MB
• Recipe Memory: 1 MB
• OS: Windows CE 5.0
• Communication Ports: MPI/PROFIBUS DP/USS, RS-232, USB
• CF Card Slot: 1 × CF for data/recipe transfer
• Power Consumption: ≈ 12 W
• Operating Temperature: 0 °C … +50 °C
• Dimensions (W × H × D): 278 × 220 × 72 mm (panel depth)
• Cut-Out Dimensions: 260 × 202 mm

Application Areas

• Operator panels for medium-size machinery and process lines
• Monitoring and control in PROFIBUS or USS networks
• Recipe management, data logging, and alarm handling
• Integration into WinCC flexible / TIA Portal projects

Advantages

• Large Display: 10.4" size delivers clear visualization of process data and graphics
• Flexible Operation: Touchscreen plus 16 keys support diverse user interactions
• Network Versatility: MPI, PROFIBUS DP and USS ensure compatibility with existing automation architectures
• Robust Design: IP65 front protection withstands wash- down and harsh environments
• Easy Data Handling: CF slot and USB port facilitate recipe transfer and firmware updates
