HMI Device | Siemens | 6AV2124-1DC01-0AX0 6AV2 124-1DC01-0AX0 SIMATIC KP400 Comfort Panel

Product Description: Siemens 6AV2124-1DC01-0AX0

The Siemens 6AV2124-1DC01-0AX0 is a compact 7-inch HMI panel from the SIMATIC Basic series, designed for reliable operator interaction in industrial environments. It features a vivid 800 × 480-pixel TFT display with 65 536 colors and supports analog-resistive touch operation. With built-in PROFINET and MPI communications, it integrates seamlessly into Siemens automation networks. Configuration is performed via WinCC Basic V13 or TIA Portal, making project setup and maintenance straightforward.

Key Features

• Display: 7" TFT color display, 800 × 480 pixels, 65 536 colors
• Operation: Analog-resistive touchscreen plus 4 programmable function keys
• Interfaces: PROFINET, MPI, 1 × RS 485, 1 × USB (up to 16 GB)
• Memory: 10 MB user memory for screens, tags and recipes
• Software Support: Configurable with WinCC Basic V13 (TIA Portal compatible)
• Protection Class: IP65 front, IP20 rear
• Power Supply: 24 V DC (19.2 … 28.8 V DC)
• Mounting: Panel mounting; standardized cut-out 190 × 138 mm

Technical Specifications

• Display Size: 7 inches
• Resolution: 800 × 480 pixels
• Number of Colors: 65 536
• Touchscreen Type: Analog- resistive
• Function Keys: 4 programmable function keys
• User Memory: 10 MB
• Operating System: WinCC Basic runtime
• Communication Protocols: PROFINET, MPI, Modbus RTU via RS 485
• USB Interface: 1 × USB port, supports up to 16 GB storage
• Power Consumption: ≈ 7 W
• Operating Temperature Range: 0 °C … +50 °C
• Dimensions (W × H × D): 215 × 157 × 51 mm
• Cut-Out Dimensions: 190 × 138 mm
• Protection Class (Front/Rear): IP65 / IP20

Application Areas

• Operator panels for machinery and production lines
• Monitoring and control in PROFINET-based automation systems
• Recipe management and data logging in small- to medium-scale plants
• User interfaces in packaging, assembly and material-handling equipment

Advantages

• Compact Footprint: 7" size fits tight spaces while delivering clear visualization
• Flexible I/O: Touchscreen plus function keys accommodate diverse operator needs
• Seamless Integration: Native PROFINET and MPI support streamlines network connectivity
• Robust Design: IP65 front protection ensures durability in wash-down or dusty environments
• Easy Configuration: WinCC Basic and TIA Portal compatibility simplify engineering and updates
