Variable Frequency Drive | Siemens | 6SE6440-2UC15-5AA1 6SE6 440-2UC15-5AA1 MICROMASTER440 without filter

Product Description: Siemens 6SE6440-2UC15-5AA1

The Siemens 6SE6440-2UC15-5AA1 is a line module in the SINAMICS S120 family, designed to feed the shared 600 V DC bus of the drive system. It accepts a 3-phase 380–480 V AC supply and provides a continuous current of 15 A. Integral protection functions—including overcurrent, short- circuit, and overvoltage protection—ensure reliable operation. The module communicates via the DRIVE-CLiQ interface for configuration and diagnostics, seamlessly integrating into the modular S120 architecture.

Key Features

• Input Voltage: 3AC 380–480 V ±10%, 47–63 Hz
• Output Current: 15 A continuous on 600 V DC bus
• Protection Functions: Overcurrent, short-circuit, overvoltage protection
• Cooling: Internal fan cooling with IP20 enclosure
• Communication Interface: DRIVE-CLiQ for parameterization and diagnostics
• Mounting: DIN-rail installation within SINAMICS S120 system

Technical Specifications

• System Series: SINAMICS S120
• Module Type: Line Module
• Input Voltage: 3AC 380–480 V ±10%
• Continuous Output Current: 15 A
• DC Link Voltage: 600 V DC
• Cooling Method: Internal fan
• Protection Functions: Overcurrent, short-circuit, overvoltage
• Communication Interface: DRIVE-CLiQ
• Mounting: DIN-rail
• Dimensions (W × H × D): Approx. 220 mm × 400 mm × 300 mm
• Operating Temperature Range: 0 °C to +40 °C (derating above +40 °C)
• Protection Class: IP20
• Certifications: CE, UL, cULus

Application Areas

• Supplying the DC bus for SINAMICS S120 motor modules
• High-performance motion control in CNC, robotics, and packaging
• Distributed drive systems requiring modular line modules
• Industrial automation with regenerative braking and energy recovery

Advantages

• Reliable DC bus power with integrated safety protection
• Compact DIN-rail design for flexible system layouts
• Simple diagnostics and commissioning via DRIVE-CLiQ
• Scalable solution for multi-axis drive configurations
