Product Description: Siemens 6ES7132-4HB01-0AB0

The Siemens 6ES7132-4HB01-0AB0 is a high-feature digital output module designed for use within the SIMATIC ET 200S distributed I/O system. This module provides 8 digital outputs with sourcing (P-type) configuration, each capable of delivering up to 0.5 A at 24 V DC. It offers enhanced functionality such as channel-specific diagnostics and parameterizable output behavior, making it ideal for applications requiring reliable switching and transparent fault detection. With a slim 15 mm module width and compatibility with standard ET 200S BaseUnits, the DO 8×24 V DC/0.5 A HF module is widely used in automation systems with limited space and high- performance requirements.

Key Features

• 8 Digital Outputs: Sourcing (PNP), 24 V DC, 0.5 A per channel
• High Feature Functionality: Includes diagnostics, substitute values, and parameterization
• Compact 15 mm Width: Saves cabinet space and supports high-density I/O configurations
• Diagnostic Support: Individual channel diagnostics for short-circuit and wire break
• Hot Swappable: Can be replaced during operation without system shutdown (with suitable BaseUnit)
• Parameterizable via TIA Portal: Configurable delay times and fault response behavior

Technical Specifications

• Product Type: Digital Output Module
• Part Number: 6ES7132-4HB01-0AB0
• Series: SIMATIC ET 200S
• Module Type: DO 8×24 V DC/0.5 A HF
• Number of Outputs: 8
• Output Type: Sourcing (PNP)
• Rated Voltage: 24 V DC
• Max Output Current: 0.5 A per channel
• Total Current Limit: 4 A (module total)
• Diagnostics: Channel-based diagnostics, short-circuit detection
• Module Width: 15 mm
• Mounting: DIN rail, on ET 200S BaseUnit (e.g., BU type E)
• Operating Temperature: 0°C to +60°C
• Protection Class: IP20 (when installed in enclosure)
• Weight: Approx. 80 g

Application Areas

• Factory Automation: Control of indicator lights, contactors, and actuators
• Packaging Machinery: Output switching for fast-paced and reliable motion control
• Process Equipment: Interfacing with solenoids, valves, and digital output devices
• High-Density I/O Systems: Efficient digital output expansion in space-constrained panels

Advantages

• High Performance in Compact Form: 8 channels in only 15 mm width
• Advanced Diagnostics: Helps reduce downtime and improve system transparency
• Flexible Configuration: Output behavior and diagnostics customizable via TIA Portal
• Reliable Operation: Designed for continuous industrial use with overload protection
• Easy Maintenance: Supports hot-swapping for fast replacement without rewiring
