PLC | Siemens | 6ED1052-1MD00-0BA6 6ED1 052-1MD00-0BA6 LOGO 12/24RC logic module

Product Description: Siemens 6ED1052-1MD00-0BA6

The Siemens 6ED1052-1MD00-0BA6 is a 7-inch touch screen HMI panel from the SIMATIC HMI series, part of the KTP 700 Basic model. This panel is designed for use in industrial automation systems to provide a user- friendly interface for monitoring and controlling processes and machinery. It features a high- resolution TFT color display and a touch-screen interface that enables easy interaction with the system. The KTP 700 Basic HMI panel supports integration with Siemens PLC systems via PROFINET, offering seamless communication in industrial networks for real-time data monitoring and control.

Key Features

• Display Size: 7-inch TFT color touchscreen
• Display Type: High-resolution TFT display for clear visualization of system parameters and control data
• User Interface: Touchscreen interface for intuitive operation and navigation through system controls
• Communication Protocols: Supports communication with Siemens PLCs using PROFINET and other industrial networks
• Programming: Configurable using Siemens TIA Portal or WinCC flexible for easy setup and integration with existing systems
• Mounting: Panel mount for integration into control cabinets or machine systems
• Operating Temperature Range: Suitable for industrial environments with an operating temperature range from 0°C to +50°C
• Diagnostic Features: Built-in diagnostics for real-time monitoring and fault detection to ensure system reliability

Technical Specifications

• Product Type: Human Machine Interface (HMI)
• Part Number: 6ED1052-1MD00-0BA6
• Display Size: 7-inch
• Display Type: TFT, high-resolution
• Touch Interface: Yes, touch-screen interface
• Communication Protocols: PROFINET, Industrial Ethernet
• Operating Temperature Range: 0°C to +50°C
• Mounting: Panel mount
• Dimensions (W x H x D): 194 mm x 150 mm x 43 mm
• Weight: Approx. 0.6 kg

Application Areas

• Factory Automation: Ideal for controlling and monitoring machines and production lines in manufacturing environments.
• Process Control: Used in industries such as food processing, pharmaceuticals, and chemicals, where monitoring and controlling industrial processes is essential.
• Machine Control: Provides a clear and easy-to-use interface for controlling machinery and automated systems.
• Building Automation: Suitable for controlling systems like HVAC, lighting, and security in building management.

Advantages

• High-Resolution Display: The TFT display provides sharp and clear visualization of data, ensuring readability even in challenging industrial environments.
• Compact and Efficient: The 7-inch size allows for space-efficient integration while providing sufficient screen space for visualizing system data.
• Flexible Integration: Supports PROFINET and Industrial Ethernet, enabling seamless integration with Siemens PLC systems and other automation equipment.
• Reliable Diagnostics: Built-in diagnostic functions help monitor system health and detect faults, reducing downtime and improving system reliability.
