HMI Device | Siemens | 6AV6545-0BB15-2AX0 SIMATIC TP 170B Touch Panel 6AV6 545-0BB15-2AX0

Product Description: Siemens 6AV6545-0BB15-2AX0

The Siemens 6AV6545-0BB15-2AX0 is a KTP700 Basic Panel, part of the SIMATIC HMI Basic Panels series. This model features a 7-inch TFT display with a touchscreen interface, designed for industrial control and automation applications. The KTP700 Basic panel provides a user-friendly interface for machine and process control, with a focus on easy operation and real-time monitoring. Equipped with a PROFINET interface, the 6AV6545-0BB15-2AX0 integrates seamlessly with Siemens S7-1200 and S7-1500 PLCs, offering a robust solution for a wide range of industrial automation tasks. Its IP65-rated front ensures reliable protection against dust and water, making it suitable for challenging industrial environments.

Key Features

• Display: 7" TFT color display with 800 x 480 pixels resolution, providing clear visuals for easy user interaction.
• Input Method: Touchscreen interface, enabling simple and intuitive operation.
• Communication: PROFINET interface for fast and reliable data exchange with Siemens PLCs.
• Protection: IP65-rated front panel, ensuring resistance to dust and water ingress for use in harsh industrial environments.
• Memory: 12 MB of memory for project storage, capable of managing large graphical interfaces and data.
• Power Supply: Operates on 24V DC for efficient energy use.
• Software Compatibility: Configured with TIA Portal for easy programming and project management.

Technical Specifications

• Display Size: 7" TFT Color Display
• Resolution: 800 x 480 pixels (WVGA)
• Touch Interface: Resistive touchscreen
• Communication Interface: PROFINET (RJ45)
• Front Protection: IP65
• Memory: 12 MB User Memory
• Power Supply: 24 V DC
• Operating Temperature: 0°C to +50°C
• Mounting Type: Panel mounting (flush installation)
• Software: Compatible with TIA Portal and WinCC

Application Areas

• Machine Control: For controlling and monitoring automation processes in manufacturing, packaging, and assembly systems.
• Process Visualization: Suitable for visualizing and interacting with process data in industries such as chemical, food, and pharmaceuticals.
• Energy Management: Used in systems where real-time monitoring and control of energy processes are essential.
• Building Automation: Ideal for use in building management systems like HVAC, lighting control, and access control.

Advantages

• High-Resolution Display: Provides clear and detailed visual feedback for better user interaction.
• Flexible Communication: Seamless integration with Siemens PLCs via PROFINET, ensuring fast and reliable data transfer.
• Robust and Durable: The IP65 protection rating ensures that the panel is resistant to dust and water, making it suitable for tough industrial environments.
• Easy to Use: The touchscreen interface makes it simple to operate, even in demanding applications.
• Software Support: Easily configurable with TIA Portal for faster project setup and updates.
