Kinetix 5700 | Allen-Bradley | 2198-K57CK-D15M AB Kinetix 5700 Feedback Connector Kit New 2198K57CKD15M

Product Description: Allen-Bradley 2198-K57CK-D15M

The Allen-Bradley 2198-K57CK-D15M is a dual-axis servo drive from the Kinetix 5700 series. Designed for high-performance motion control applications, it supports CIP Motion over EtherNet/IP and delivers continuous output current of 15 A per axis. This drive simplifies integration with Logix controllers and offers high-speed performance for multi-axis systems.

Key Features

• Dual-axis inverter for coordinated motion control
• Continuous output current: 15 A per axis
• Peak output current: Up to 30 A
• Supports CIP Motion over EtherNet/IP
• Optimized for integration with Studio 5000 and Logix platforms
• Compatible with Kinetix VP and MP-series servo motors
• Integrated advanced safety features including Safe Torque-Off (STO)
• DIN rail mountable for easy panel installation
• High-resolution feedback support for precise control

Technical Specifications

• Axes: 2 (dual- axis)
• Continuous Output Current: 15 A per axis
• Peak Output Current: 30 A
• Input Voltage: 460V AC, 3-phase
• Communication: EtherNet/IP with CIP Motion
• Motor Feedback: Supports single-turn and multi-turn encoders
• Safety: Integrated STO (SIL3, PLe, Cat 4)
• Enclosure: Open type (IP20)
• Mounting: Panel mount via DIN rail
• Operating Temperature: 0°C to +50°C
• Certifications: UL, cUL, CE, TUV, RoHS

Application Areas

• High-speed packaging machines
• Multi-axis robotic arms
• Material handling systems
• Precision CNC and machining equipment
• Printing and textile automation

Advantages

• Dual-axis control reduces panel space and cost
• High current capacity supports demanding servo loads
• Integrated EtherNet/IP simplifies system architecture
• Safety features ensure compliance and protection
• Fast commissioning using Studio 5000 environment
