Product Description: Allen-Bradley 1783-BMS10CGN

The Allen-Bradley 1783-BMS10CGN is a Layer 2 managed modular Ethernet switch from the Stratix 8000 series, featuring 10 Fast Ethernet (10/100 Mbps) copper ports and 2 Gigabit SFP ports for fiber or copper transceivers. This switch integrates industrial hardened hardware with Cisco IOS software, enabling full network management and compatibility with both enterprise and automation systems.

Key Features

• 10 auto-sensing 10/100 Mbps RJ45 copper ports
• 2 SFP (Small Form-Factor Pluggable) slots for 1 Gbps uplink modules
• Full Layer 2 managed functionality using Cisco IOS
• Supports VLANs, QoS, IGMP snooping, port mirroring, and port security
• Device Level Ring (DLR), Spanning Tree Protocol (STP), and Rapid STP
• Rockwell Automation Add-On Profile (AOP) and integration with Studio 5000
• DIN rail or panel mounting
• USB port and console port for configuration and updates

Technical Specifications

• Total Ports: 10 copper + 2 SFP (fiber or copper)
• Speed: 10/100 Mbps (copper), 1 Gbps (SFP)
• MAC Table: 8000 entries
• Power Supply: 24V DC nominal, dual inputs supported
• Power Consumption: Approx. 14–18 W
• Enclosure: Metal, IP30 rated
• Mounting: DIN rail or panel mount
• Operating Temperature: -40°C to +60°C
• Dimensions (H x W x D): Approx. 125 mm x 195 mm x 130 mm
• Certifications: UL, CE, cULus, RoHS, CSA, ATEX Zone 2, IECEx

Application Areas

• Industrial automation networks requiring fiber uplink
• Layered and segmented control networks
• High- performance machinery and process control systems
• Networked PLCs and distributed I/O over EtherNet/IP
• Harsh environments requiring rugged networking solutions

Advantages

• Combines industrial ruggedness with Cisco network standards
• SFP uplinks enable flexible fiber or copper expansion
• Modular design supports system scalability
• Full Rockwell and Logix system integration
• Network diagnostics, traffic control, and security features included
