Allen-Bradley | 1756-IF16H | ControlLogix (1756)

Product Description: Allen-Bradley 1756-IF16H

The Allen-Bradley 1756-IF16H is a high-density analog input module with HART communication support, designed for ControlLogix systems. It features 16 differential analog input channels that can be configured individually for either 0–20 mA or 4–20 mA signals. The module enables simultaneous analog signal processing and HART digital communication, allowing configuration, diagnostics, and monitoring of HART field devices directly through the control system.

Key Features

• 16 individually configurable differential analog input channels
• Supports 0–20 mA and 4–20 mA signal ranges
• HART communication support on all channels
• Compatible with HART versions 5, 6, and 7
• Integrated Add-On Profile (AOP) in Studio 5000 Logix Designer
• Advanced diagnostics and asset management through HART
• Removal and Insertion Under Power (RIUP)
• Supports redundant ControlLogix systems

Technical Specifications

• Channels: 16 differential analog inputs
• Input Signal: 0–20 mA or 4–20 mA per channel
• HART Compatibility: Versions 5, 6, 7
• Resolution: 16 bits
• Isolation: 250V (channel-to-backplane and channel-to-channel)
• Backplane Current Draw:
  • 5.1V DC: ~250 mA
• Power Dissipation: ~6.6 W
• Operating Temperature: 0°C to +60°C
• Mounting: ControlLogix chassis (1756 series)
• Enclosure Type: Open (IP20)
• Certifications: UL, CE, cULus, ATEX, IECEx, RoHS

Application Areas

• Process control systems with analog and HART-enabled instruments
• Chemical and pharmaceutical manufacturing
• Oil and gas field I/O and diagnostics
• Utilities and water treatment
• Advanced instrumentation systems requiring digital diagnostics

Advantages

• Combines analog signal processing and digital HART communication
• Reduces need for additional HART multiplexers
• Provides real-time access to device health and process data
• Flexible integration into ControlLogix architectures
• Enhances productivity through centralized configuration and diagnostics
