Product Description: Schneider Electric ATV71HD15N4Z

The Schneider Electric ATV71HD15N4Z is a high- performance variable speed drive designed for controlling three-phase asynchronous motors in complex, high- power industrial applications. Part of the Altivar 71 series, this drive offers advanced motor control capabilities, integrated safety features, and flexible communication options, making it suitable for demanding environments.

Key Features

• Motor Power: 15 kW (20 HP)
• Supply Voltage: 380–480 V AC, three-phase
• Integrated EMC Filter: Ensures compliance with electromagnetic compatibility standards
• Control Profiles: Supports various motor control methods including vector control with or without sensor
• Communication Protocols: Built-in CANopen and Modbus for seamless integration
• Safety Function: Power Removal function for enhanced operational safety
• Design: Compact with heat sink cooling; does not include a graphic display terminal

Technical Specifications

• Input Voltage Range: 380–480 V AC, 3-phase
• Line Frequency: 50/60 Hz
• Output Frequency: 0.1 to 599 Hz
• Nominal Output Current: 27 A at 4 kHz switching frequency
• Apparent Power: 31.6 kVA at 380 V
• Maximum Motor Cable Length:
  • 50 m (shielded)
• Mounting: Vertical mounting with heat sink
• Protection Rating: IP20
• Operating Temperature: Up to 50°C with appropriate derating

Application Areas

• Material handling systems
• Packaging machinery
• Textile industry equipment
• Process control applications
• Industrial automation requiring precise motor control

Advantages

• High- performance motor control for complex applications
• Integrated safety features enhance operational safety
• Flexible communication options for easy integration
• Compact design saves panel space
• Compliance with international standards for electromagnetic compatibility
