Model: 8V1090.00-2
Product Type: AC Servo Drive
Series: B&R ACOPOS 1090

Description:
The 8V1090.00-2 is a high-performance AC servo drive from B&R’s ACOPOS 1090 series, designed for precise motion control in industrial automation applications. It operates on a 3-phase 400–480 VAC supply and provides a continuous output current of 8.8 A, suitable for driving medium to large-sized synchronous and asynchronous motors. The drive features integrated components such as a line filter, braking resistor, and electronic safe restart inhibit, ensuring compliance with electromagnetic compatibility (EMC) standards and enhancing system safety and reliability.

Key Features:

• Rated Current: 8.8 A
• Power Rating: 4.0 kW
• Supply Voltage: 3 × 400–480 VAC
• Cooling Method: Natural convection
• Integrated Components: Line filter, braking resistor, electronic safe restart inhibit
• Compliance: Meets EN 61800-3 Category C3 EMC standards
• Mounting: Modular design for easy integration into control cabinets
• Protection Class: IP20 (suitable for indoor use)
• Dimensions: 70.5 × 375 × 235.5 mm
• Weight: Approximately 4.0 kg

Applications:

• Robotics & Handling Systems: Precise control of robotic arms and automated handling equipment
• Packaging Machinery: Efficient operation in packaging lines requiring accurate motion control
• Material Handling: Reliable performance in conveyor systems and automated storage solutions
• OEM Automation Equipment: Flexible integration into custom machine designs for various industries

Technical Specifications:

• Rated Output Current: 8.8 A
• Power Rating: 4.0 kW
• Supply Voltage: 3 × 400–480 VAC
• Cooling Method: Natural convection
• Integrated Components: Line filter, braking resistor, electronic safe restart inhibit
• Compliance: EN 61800-3 Category C3 EMC standards
• Mounting: Modular design for control cabinets
• Protection Class: IP20
• Dimensions: 70.5 × 375 × 235.5 mm
• Weight: Approximately 4.0 kg
