Product Description: Schneider Electric ABL8RPS24030

The Schneider Electric ABL8RPS24030 is a single-phase regulated switch mode power supply designed to convert AC voltage into regulated 24 VDC output. With a 3 A current rating and wide input voltage range, it is suitable for powering control circuits, sensors, and PLC systems in industrial automation environments.

Key Features

• Output voltage: 24 VDC
• Output current: 3 A
• Rated output power: 72 W
• Input voltage range:
  • AC: 100–500 V AC (single-phase)
• Input frequency: 50/60 Hz
• Efficiency: Up to 90%
• Output voltage adjustment range: 22–28 V DC
• Integrated short-circuit and overload protection
• Built-in LED status indicator
• Double insulation (Class II)

Technical Specifications

• Line and load regulation: ±1%
• Ripple voltage: ≤ 100 mV peak-to-peak
• Dielectric strength: 3000 V between input and output
• Connection: Screw terminals
• Mounting: DIN rail (35 mm)
• Cooling: Natural convection
• Protection degree: IP20
• Operating temperature: -10°C to +60°C (without derating)
• Storage temperature: -40°C to +85°C
• Dimensions (W x H x D): Approx. 70 mm x 120 mm x 110 mm
• Weight: Approx. 0.8 kg

Application Areas

• Control panel power supplies
• Programmable logic controllers (PLCs)
• Industrial automation and factory equipment
• Building management systems
• Instrumentation and sensor power

Advantages

• Wide input voltage range suitable for global applications
• Stable and regulated 24 VDC output for sensitive electronics
• Compact design for space-constrained control panels
• Reliable protection features for overload, short-circuit, and overvoltage
• Easy DIN rail installation and maintenance
