Product Description: Siemens 6SN1145-1BA01-0BA2

The Siemens 6SN1145-1BA01-0BA2 is an infeed/regenerative power module from the SIMODRIVE 611 series, designed to supply power to the drive modules in high- performance motion control systems. This module supports both energy infeed and regenerative feedback to the supply network, with a rated power capacity of 16/21 kW. It is internally cooled and designed for cabinet mounting. This power module ensures efficient energy management in CNC machines, printing lines, packaging systems, and other high-speed, high- precision industrial machinery. It is compatible with SIMODRIVE 611 universal or digital control units and meets industrial requirements for reliability, robustness, and integration.

Key Features

• Infeed/Regenerative Functionality: Allows both power supply and energy recovery to the grid.
• High Power Rating: Supports 16 kW continuous and up to 21 kW peak regenerative power.
• Internal Cooling: Designed with integrated fans for cabinet-based air cooling.
• Modular System Integration: Part of the flexible and scalable SIMODRIVE 611 platform.
• Diagnostics and Monitoring: Supports status signaling and fault diagnostics via control unit.
• High Efficiency: Reduces energy consumption by feeding braking energy back into the supply.

Technical Specifications

• Product Type: Power Infeed/Regenerative Module
• Part Number: 6SN1145-1BA01-0BA2
• Series: SIMODRIVE 611
• Rated Power: 16 kW continuous / 21 kW regenerative
• Input Voltage: 3AC 400 V ±10%
• Cooling Method: Internal cooling with fan
• Regenerative Capability: Yes (feedback to mains)
• Mounting: Control cabinet (vertical orientation)
• Protection Features: Overvoltage, overload, short-circuit protection
• Communication: Via SIMODRIVE control unit
• Dimensions (W x H x D): Approx. 150 × 340 × 250 mm
• Weight: Approx. 10–12 kg

Application Areas

• CNC Machine Tools: Supplies servo and spindle drives for precision machining.
• Textile and Printing Machines: Supports rapid acceleration and deceleration cycles.
• Packaging Equipment: Provides dynamic motion control with energy regeneration.
• Automation Lines: Powers multi-axis drives in high-performance systems.

Advantages

• Energy Efficiency: Regenerates braking energy to reduce total power consumption.
• Flexible Integration: Compatible with a wide range of SIMODRIVE 611 modules.
• Compact and Scalable: Easily fits into modular systems with high-power requirements.
• Industrial-Grade Durability: Designed for continuous operation in demanding environments.
• Safe and Reliable: Built-in protection mechanisms ensure operational stability.
