Drives/Drive Modules | Siemens | 6SN1123-1AA00-0EA2 6SN1 123-1AA00-0EA2 SIMODRIVE 611 POWER MODULE

Product Description: Siemens 6SN1123-1AA00-0EA2

The Siemens 6SN1123-1AA00-0EA2 is a CU310-2 PN control unit from the SINAMICS S120 series, engineered for standard drive and motion control tasks. It features an integrated PROFINET interface for seamless real-time communication with PLCs and higher-level controllers. The CU310-2 PN uses the DRIVE-CLiQ protocol to link with power modules, enabling rapid parameterization, diagnostics, and firmware updates via TIA Portal or STARTER software. Housed in an IP20 DIN-rail enclosure, it delivers reliable performance in industrial environments.

Key Features

• Control Unit: CU310-2 PN for standard speed and torque control
• Network Interface: PROFINET IRT/RT up to 100 Mbps for cyclic and acyclic data
• Drive Interface: DRIVE-CLiQ port for connection to PM modules and I/O
• Diagnostics: LEDs for status (“Ready,” “Error,” “Bus”) and detailed fault logging via software
• Parameterization: Via TIA Portal or STARTER over PROFINET or DRIVE-CLiQ
• Safety Functions: Supports Safe Torque Off (STO) when wired to an external safety relay
• Mounting & Protection: Snap-on DIN-rail, IP20 enclosure
• Power Supply: 24 V DC logic supply

Technical Specifications

• Control Unit Model: CU310-2 PN
• PROFINET Data Rate: up to 100 Mbps (IRT/RT)
• DRIVE-CLiQ Ports: 2 ports (daisy-chain topology)
• Logic Supply Voltage: 24 V DC (19.2 … 28.8 V DC)
• Power Consumption: ≈ 5 W
• Diagnostics Indicators: LEDs: Ready, Error, Bus
• Mounting: 35 mm DIN-rail, IP20
• Operating Temperature Range: 0 °C … +60 °C
• Dimensions (W × H × D): 45 mm × 125 mm × 102 mm
• Weight: ≈ 0.15 kg

Application Areas

• Closed-loop speed and torque control of motors in conveyors, pumps, and fans
• Integration into PROFINET-based automation architectures
• Modular multi-axis motion systems when paired with SINAMICS S120 power modules
• Standard machinery requiring straightforward commissioning and diagnostics

Advantages

• High-Speed Ethernet: PROFINET IRT for deterministic control and top-level system integration
• Seamless Drive Network: DRIVE-CLiQ autoconfiguration accelerates commissioning of PM modules
• Flexible Diagnostics: On-board LEDs plus software-based fault analysis minimize downtime
• Safety Ready: Supports STO hardware implementation without additional control units
• Compact & Robust: Narrow 45 mm footprint and IP20 protection save cabinet space and ensure reliability
