Drives/Drive Modules | Siemens | 6SN1123-1AA00-0EA0 6SN1 123-1AA00-0EA0 SIMODRIVE 611 power module

Product Description: Siemens 6SN1123-1AA00-0EA0

The Siemens 6SN1123-1AA00-0EA0 is a DIN-rail mounted control unit from the SINAMICS S120 modular drive family. As the CU310-2 DP variant, it provides essential control functionality with a built-in PROFIBUS DP interface for communication with PLCs and higher-level automation systems. Designed for standard motion tasks, it supports cyclic and acyclic data exchange, basic diagnostics, and parameter management via the DRIVE-CLiQ network. The CU310-2 DP pairs with power modules (PM) to form a complete drive axis in applications such as conveyors, pumps, and fans.

Key Features

• Control Unit: CU310-2 DP for standard drive control
• Communication Interface: PROFIBUS DP up to 12 Mbit/s
• Network Protocol: DRIVE-CLiQ for connection to power modules and I/O
• Diagnostics: Basic status and fault reporting via LEDs and bus diagnostics
• Parameterization: Via Siemens STARTER or TIA Portal software over DRIVE-CLiQ or DP
• Mounting: Snap-on DIN-rail housing, IP20 protection
• Power Supply: 24 V DC logic supply

Technical Specifications

• Control Unit Model: CU310-2 DP
• PROFIBUS DP Data Rate: up to 12 Mbit/s
• DRIVE-CLiQ Ports: 2 ports (daisy-chain topology)
• Logic Supply Voltage: 24 V DC (19.2 … 28.8 V DC)
• Power Consumption: ≈ 5 W
• Diagnostics: LEDs for “Ready,” “Error,” “Bus”
• Mounting: 35 mm DIN-rail, IP20
• Operating Temperature: 0 °C … +60 °C
• Dimensions (W × H × D): 45 mm × 125 mm × 102 mm
• Weight: ≈ 0.15 kg

Application Areas

• Standard speed and torque control of asynchronous and permanent-magnet motors
• Conveyor systems, pumps, fans, and material-handling equipment
• Integration into PROFIBUS DP- based automation architectures
• Basic motion control tasks in machine and plant automation

Advantages

• Compact Design: Narrow 45 mm module conserves control cabinet space
• Seamless Integration: DRIVE-CLiQ network simplifies wiring to power modules
• Easy Commissioning: Parameterize and diagnose via STARTER or TIA Portal
• Reliable Operation: Robust IP20 housing and wide temperature range for industrial environments
• Cost-Effective: Provides essential control features without the complexity of higher-end CU variants
