Product Description: Siemens 6SN1123-1AA00-0AA1

The Siemens 6SN1123-1AA00-0AA1 is a 1-axis inverter power module from the SIMODRIVE 611 Universal series, designed to control a single motor in modular CNC or motion control applications. It provides a continuous current output of 25 A and is compatible with both synchronous and asynchronous motors. This unit operates as part of a complete SIMODRIVE 611 system, requiring a compatible control unit (CU) and power supply module. The module is cooled via internal forced-air ventilation and is optimized for use in industrial environments with high reliability and minimal maintenance.

Key Features

• Continuous Output Current: 25 A
• Compatible Motor Types: Servo and induction motors
• Integrated Functions: Speed and torque control, dynamic braking (with external resistor)
• Cooling: Internal forced-air cooling system
• Interface: Backplane bus connection to SIMODRIVE control unit
• Protection Class: IP20 for control cabinet installation
• Diagnostics: LED status indicators and communication via CU

Technical Specifications

• Rated Output Current: 25 A continuous
• Peak Current: Up to 37.5 A (150% for short durations)
• DC Link Voltage: 600 V DC nominal (540–670 V DC range)
• Output Voltage: 3 × 400 V AC
• Cooling Method: Internal forced air
• Dimensions (W × H × D): Approx. 50 mm × 270 mm × 375 mm
• Weight: Approx. 6.5 kg
• Mounting: Booksize vertical mounting
• Operating Temperature: 0 °C … +40 °C (derating above 40 °C)
• Communication: SIMODRIVE system bus via backplane
• Protection Class: IP20

Application Areas

• CNC machines (milling, turning, grinding)
• Packaging, printing, and textile machines
• Industrial automation requiring dynamic 1-axis motor control
• Retrofitting and expansion of existing SIMODRIVE 611 installations

Advantages

• Reliable Performance: Proven solution for high-precision motor control
• Modular Integration: Fits seamlessly into SIMODRIVE 611 systems with scalable architecture
• Compact Design: Booksize format saves valuable cabinet space
• High Flexibility: Supports a wide range of motor types and control requirements
• Serviceability: Easy replacement and built-in diagnostics reduce downtime
