Product Description: Siemens 6SL3224-0BE25-5UA0

The Siemens 6SL3224-0BE25-5UA0 is a PM240-2 Power Module from the SINAMICS G120 modular drive series, rated for 55 kW motor output power. It is designed for demanding industrial applications requiring dynamic motor control and energy efficiency. Operating on a 3-phase 380–480 V AC input, this power module provides regenerative braking capability (when paired with a braking resistor) and supports a wide range of motion control needs in conveyor, pump, fan, and compressor systems. This module is compatible with SINAMICS Control Units (CU230, CU240, CU250) and allows flexible system configuration. It features internal air cooling and comes without an integrated EMC filter, giving the user the flexibility to select an external filter if required.

Key Features

• 55 kW Rated Output Power: Suitable for large motors in high-performance applications
• Modular Design: Combines with G120 Control Units for tailored solutions
• Regenerative Braking Support: Includes built-in braking chopper
• Frame Size F: Designed for higher power applications with optimized cabinet space usage
• No Integrated Filter: Allows custom EMC filtering solutions based on application needs
• Comprehensive Protection: Includes overvoltage, overload, and short-circuit protection

Technical Specifications

• Product Type: Power Module (PM240-2)
• Part Number: 6SL3224-0BE25-5UA0
• Series: SINAMICS G120
• Rated Power Output: 55 kW
• Input Voltage: 3AC 380–480 V ±10%, 47–63 Hz
• Output Current: Approx. 98 A
• Braking Chopper: Integrated (external resistor required)
• Cooling Method: Internal air cooling
• Integrated Filter: No (external EMC filter optional)
• Frame Size: F
• Protection Class: IP20 (for cabinet installation)
• Mounting Orientation: Vertical
• Communication: Via compatible SINAMICS Control Unit (CU)
• Operating Temperature: -10°C to +50°C (up to +60°C with derating)
• Dimensions (W × H × D): Approx. 275 × 700 × 320 mm (Frame Size F)
• Weight: Approx. 38–40 kg

Application Areas

• Material Handling: Conveyor belts, hoists, gantry cranes
• Pumps and Fans: Energy-efficient speed control in HVAC and water systems
• Compressors and Blowers: Precise torque and speed regulation
• General Industrial Machinery: Suitable for production lines and packaging equipment

Advantages

• Flexible System Design: Modular architecture allows separation of control and power
• Energy Efficiency: Braking energy can be safely dissipated using external resistors
• Scalable and Adaptable: Compatible with multiple control units and communication protocols
• High Reliability: Built for continuous operation in harsh industrial environments
• Optimized Footprint: Compact for its power class, ideal for retrofits and new builds alike
