Servo Drive | Siemens | 6SL3 224-0BE17-5UA0 6SL3224-0BE17-5UA0 G120 PM 240 Power Module

Product Description: Siemens 6SL3224-0BE17-5UA0

The Siemens 6SL3224-0BE17-5UA0 is a power module from the SINAMICS G120P series, designed for controlling pumps, fans, and compressors. It provides a rated output power of 11 kW and 22 A current, operating on a 3-phase 400 V AC supply. The module includes advanced features such as energy- saving functions and integrated braking chopper functionality. It is part of a modular system that can be expanded and customized to meet specific needs for industrial automation, providing high-performance and reliable operation.

Key Features

• Power Rating: 11 kW (approx. 15 HP)
• Input Voltage: 3AC 380–480 V ±10%, 47–63 Hz
• Output Current: 22 A
• Control Modes: V/f, Sensorless Vector Control (SVC)
• Braking Unit: Integrated braking chopper for dynamic braking
• Cooling: Internal fan cooling with compact IP20 housing
• Communication Interface: PROFINET, RS485 (USS/Modbus RTU), and optional fieldbus modules
• Configuration: Via SINAMICS Startdrive in TIA Portal or IOP/IOP-2 panel

Technical Specifications

• System Series: SINAMICS G120P
• Module Type: Power Module
• Input Voltage: 3AC 380–480 V ±10%
• Output Power: 11 kW
• Output Current: 22 A
• Control Methods: V/f, Sensorless Vector Control (SVC)
• Communication Interface: PROFINET, RS485 (USS/Modbus RTU), I/O
• Braking Unit: Integrated
• Cooling Method: Internal fan
• Protection Class: IP20
• Dimensions (W × H × D): Approx. 150 mm × 380 mm × 215 mm
• Operating Temperature Range: -10 °C to +50 °C (derating above +40 °C)
• Certifications: CE, UL, cULus

Application Areas

• Variable-speed control for fans, pumps, and compressors
• HVAC systems and water treatment plants
• Material handling systems such as conveyors and mixers
• Energy-efficient solutions for industrial process automation

Advantages

• High efficiency with integrated energy-saving functions
• Modular, scalable design to fit different applications
• Integrated braking functionality for dynamic load applications
• Easy integration with SINAMICS and Siemens PLC systems via PROFINET
