Product Description: Siemens 6FC5303-0AF22-0AA1

The Siemens 6FC5303-0AF22-0AA1 is a double motor module designed for use with SINAMICS S120 drive systems in SINUMERIK CNC automation environments. It features two independent motor outputs, each rated at 16 A, and operates with a DC link voltage of 600 V. This module enables high- performance control of two motors from a single compact unit, making it ideal for space-efficient multi-axis machine tools. It supports precise torque, speed, and position control, and connects via the DRIVE-CLiQ interface for system integration and diagnostics.

Key Features

• Motor Channels: 2 independent outputs
• Output Current: 2 × 16 A continuous
• DC Link Voltage: 600 V DC (shared DC bus)
• Cooling: Booksize format with internal fan cooling
• Communication: DRIVE-CLiQ for configuration and diagnostics
• Mounting: Booksize, side-by-side installation on mounting rail
• System Integration: For SINAMICS S120 drive line and SINUMERIK CNC

Technical Specifications

• System Series: SINAMICS S120 / SINUMERIK
• Module Type: Double Motor Module
• DC Link Voltage: 600 V DC
• Output Current: 2 × 16 A
• Supported Motors: Synchronous and asynchronous motors
• Communication Interface: DRIVE-CLiQ
• Cooling Method: Internal fan
• Mounting Type: Booksize, side-by-side
• Dimensions (W × H × D): Approx. 100 mm × 380 mm × 270 mm
• Operating Temperature Range: 0 °C to +40 °C (up to +55 °C with derating)
• Protection Class: IP20
• Certifications: CE, UL, cULus

Application Areas

• Multi-axis CNC machines in metal cutting and manufacturing
• Motion control for robotics, assembly, and packaging lines
• High-performance drive systems requiring compact multi-motor control
• Integrated automation with SINUMERIK 840D/828D and S120

Advantages

• Two motor outputs in one module for space-saving installation
• High dynamic response for precise axis control
• Seamless integration into SINAMICS and SINUMERIK architectures
• Enhanced diagnostics via DRIVE-CLiQ interface
