Communication Module | Siemens | 6ES7532-5HF00-0AB0 S7-1500 analog output module 6ES7532-5HF00-0AB0

Product Description: Siemens 6ES7532-5HF00-0AB0

The Siemens 6ES7532-5HF00-0AB0 is an analog output module from the SIMATIC S7-1500 series, designed to provide eight high-resolution analog output channels for voltage and current signals. Supporting a resolution of 16 bits, it is ideal for precise analog control tasks such as valve positioning, actuator control, and analog interfacing in advanced automation systems. Configurable via the TIA Portal, this module ensures accurate and stable signal generation in demanding industrial environments.

Key Features

• Analog Outputs: 8 channels, configurable as voltage or current
• Signal Types: 0–10 V, ±10 V, 0–20 mA, 4–20 mA
• Resolution: 16 bits
• Diagnostics: Channel-specific diagnostics and monitoring
• Protective Functions: Short- circuit and wire break diagnostics
• Mounting: DIN rail mounting within S7-1500 system rack
• Configuration: TIA Portal (STEP 7 Professional V13 or higher)

Technical Specifications

• System Series: SIMATIC S7-1500
• Module Type: Analog Output Module (Standard)
• Number of Outputs: 8
• Signal Output Types: Voltage: 0–10 V, ±10 V / Current: 0–20 mA, 4–20 mA
• Resolution: 16 bits
• Diagnostic Functions: Yes (per channel)
• Power Supply: Via backplane bus
• Dimensions (W × H × D): 35 mm × 147 mm × 129 mm
• Operating Temperature Range: 0 °C to +60 °C
• Protection Class: IP20
• Certifications: CE, cULus, RCM, KC

Application Areas

• Precision control of actuators, drives, and valves
• Process automation systems requiring accurate analog output
• Scalable analog signal generation in modular control architectures
• Machine control and industrial instrumentation

Advantages

• High channel density with 16-bit resolution for accurate control
• Flexible output types support a wide range of field devices
• Built-in diagnostics improve maintenance and reduce downtime
• Fully integrated with TIA Portal for seamless engineering
