PLC | Siemens | 6ES7314-1AG14-0AB0 6ES7 314-1AG14-0AB0 Central processing unit

Product Description: Siemens 6ES7314-1AG14-0AB0

The Siemens 6ES7314-1AG14-0AB0 is a CPU module from the SIMATIC S7-300 series, model CPU 314, designed for standard automation tasks. It features integrated interfaces for MPI (Multi-Point Interface) and PROFIBUS DP, making it suitable for distributed automation environments. This CPU is ideal for medium- complexity control applications across various industries, including manufacturing, processing, and infrastructure automation. The CPU 314 offers a balanced combination of memory, processing performance, and communication capabilities. It supports modular expansion with S7-300 I/O and function modules and is programmed using the Siemens STEP 7 engineering software.

Key Features

• Integrated Communication: Built-in MPI/DP interface for networking with HMIs, drives, and remote I/O.
• Program and Data Memory: Includes 128 KB of work memory for user programs and data.
• Modular Scalability: Supports wide range of S7-300 signal and function modules.
• Consistent Diagnostics: Offers system diagnostics for efficient troubleshooting.
• Deterministic Control: Real-time capable for time-sensitive automation processes.
• DIN Rail Mounting: Standard S7-300 profile for seamless rack integration.

Technical Specifications

• Product Type: Central Processing Unit (CPU)
• Part Number: 6ES7314-1AG14-0AB0
• Series: SIMATIC S7-300
• CPU Model: CPU 314
• Work Memory: 128 KB
• Load Memory: Expandable via MMC
• Integrated Interfaces: 1 × MPI/DP (PROFIBUS DP Slave/Master)
• Cycle Time: Approx. 0.1 µs per instruction
• Power Supply: 24 V DC
• Digital I/O: None onboard (requires I/O modules)
• Communication Protocols: MPI, PROFIBUS DP
• Mounting: DIN rail in S7-300 rack
• Operating Temperature: 0°C to +60°C
• Weight: Approx. 300 g
• Dimensions (W x H x D): 40 × 125 × 130 mm (approx.)

Application Areas

• General Automation: Suitable for sequence control, data processing, and interlocking.
• Distributed Control Systems: Connects to PROFIBUS DP networks for remote I/O and drives.
• Industrial Machinery: Controls machinery in textile, food, packaging, and material handling.
• Process Monitoring: Used in small to mid-sized continuous or batch processes.

Advantages

• Integrated Networking: Ready for use in distributed PROFIBUS environments.
• Modular and Flexible: Expands with digital/analog I/O and communication modules.
• Cost-Effective Performance: Balances computing power and cost for standard tasks.
• Reliable Operation: Proven performance in industrial automation for years.
• TIA Portal Compatibility: Configured and programmed using Siemens engineering tools.
