PLC | Siemens | 6ES7241-1CH32-0XB0 SIMATIC S7-1200 CM 1241 6ES7 241-1CH32-0XB0

Product Description: Siemens 6ES7241-1CH32-0XB0

The Siemens 6ES7241-1CH32-0XB0 is a 32-channel digital output module designed for the SIMATIC S7-1200 PLC system. This module provides 32 digital outputs and is ideal for controlling various types of field devices such as relays, solenoids, indicators, and other actuators. It operates with a 24 V DC supply voltage and features a maximum output current of 0.5 A per channel. The module also includes diagnostic features, enabling real-time monitoring of output statuses and fault detection.

Key Features

• Number of Outputs: 32 digital outputs
• Output Type: Source output (PNP, P-switching)
• Supply Voltage: 24 V DC (permissible range: 19.2 V to 28.8 V)
• Output Current per Channel: 0.5 A
• Total Module Current: Maximum 8 A
• Diagnostics: Short-circuit to L+, wire break, supply voltage monitoring
• Mounting Compatibility: Fits to SIMATIC S7-1200 backplane bus
• Compact Design: Suitable for space-saving installations in control cabinets
• Temperature Range: Operates reliably in industrial environments

Technical Specifications

• Product Type: Digital Output Module
• Part Number: 6ES7241-1CH32-0XB0
• Number of Outputs: 32
• Output Type: Source output (PNP, P-switching)
• Supply Voltage: 24 V DC
• Output Current per Channel: 0.5 A
• Total Module Current: Maximum 8 A
• Diagnostics: Short-circuit to L+, wire break, supply voltage monitoring
• Mounting: SIMATIC S7-1200 backplane bus
• Dimensions (W x H x D): 40 mm x 125 mm x 120 mm
• Weight: Approx. 250 g

Application Areas

• Factory Automation: Control of actuators, relays, solenoids, and other devices in automated manufacturing environments.
• Process Control: Switching of devices and controlling machines or processes in industries such as chemicals, food processing, and packaging.
• Building Automation: Can be used for controlling building systems such as lighting, HVAC, and alarms.
• Energy Management: Ideal for controlling energy-consuming devices and systems to optimize energy usage in industrial settings.

Advantages

• High Channel Density: 32 outputs in a single compact module, saving valuable space in control panels.
• Reliable Diagnostics: Diagnostic LEDs provide clear feedback on each output, making it easier to detect faults and perform maintenance.
• Easy Integration: Seamlessly integrates into the SIMATIC S7-1200 system, offering flexible and scalable automation solutions.
• Robust Design: Built for industrial environments, ensuring durability and long-term performance.
