Industrial Communication | Siemens | 6ES7138-4HA00-0AB0 6ES7138-4HA00-0AB0 DP Master Interface

Product Description: 6ES7138-4HA00-0AB0

The 6ES7138-4HA00-0AB0 is a failsafe digital output module for the SIMATIC ET 200S distributed I/O family. It provides eight electronically isolated 24 V DC outputs, each rated at 0.5 A, with integrated channel diagnostics (short- circuit, overload, wire-break). Certified to SIL 3 (IEC 61508) and PL e (EN ISO 13849-1), it interfaces via PROFIsafe over PROFIBUS or PROFINET (with the appropriate interface module) to deliver safe actuator control in emergency- stop, interlock, or safety-circuit applications.

Key Features

• 8 failsafe transistor outputs, 24 V DC, 0.5 A per channel
• Safety Integrity Level: SIL 3, Performance Level e, Category 4
• Per-channel diagnostics: short-circuit, overload and wire-break detection
• PROFIsafe communication via ET 200S interface module (e.g., IM 151-F)
• High-feature version with configurable output behavior
• Status LEDs for each output and module health

Technical Specifications

• Number of Outputs: 8
• Output Type: Transistor (sourcing), 24 V DC
• Rated Load Current: 0.5 A per channel
• Isolation: 500 V DC channel-to-backplane
• Diagnostic Functions: Short-circuit, overload, wire-break
• Safety Standards: SIL 3 (IEC 61508), PL e (EN ISO 13849-1), Cat. 4
• Communication: PROFIsafe over PROFIBUS/PROFINET (via IM)
• Module Width: 15 mm
• Mounting: DIN-rail via ET 200S BaseUnit
• Operating Temperature: 0 °C … +60 °C
• Protection Class: IP20
• Weight: ≈ 90 g

Application Areas

• Emergency-stop circuits and safety interlocks
• Actuator control in safety-critical machinery (valves, solenoids, contactors)
• Integration into fail-safe distributed I/O for machine and plant safety
• Systems requiring on-the-fly module replacement with continuous safety diagnostics

Advantages

• Fully integrated safety functions eliminate external relays
• High-density, slim 15 mm module saves cabinet space
• Quick fault localization via per-channel diagnostics
• Seamless engineering in TIA Portal with Safety Integrated tools
• Proven performance in SIL 3/PL e safety applications
