Product Description: Siemens 6ES7136-6BA01-0CA0

The Siemens 6ES7136-6BA01-0CA0 is a high-feature fail- safe digital output module from the SIMATIC ET 200SP series. It provides four fail-safe digital output channels for 24 V DC signals with a maximum output current of 0.5 A per channel. This module is designed for safety-related applications up to SIL 3 (IEC 61508) and PL e (ISO 13849) and is suitable for use in safety systems requiring precise and reliable shutdown of actuators. Configuration and parameterization are done via the TIA Portal.

Key Features

• Outputs: 4 fail-safe digital outputs, 24 V DC
• Output Current: 0.5 A per channel
• Safety Integrity: Supports SIL 3 (IEC 61508), PL e (ISO 13849)
• Operation Modes: Standard or fail-safe output control
• Diagnostics: Channel- specific diagnostics and short-circuit monitoring
• Mounting: On ET 200SP Base Unit (BU type A0, A1, or A2)
• Configuration: TIA Portal (STEP 7 Safety Advanced V13 or higher)

Technical Specifications

• System Series: SIMATIC ET 200SP
• Module Type: Fail-Safe Digital Output Module
• Number of Outputs: 4
• Output Voltage: 24 V DC
• Output Current per Channel: 0.5 A
• Switching Delay: <1 ms
• Safety Level: SIL 3, PL e
• Diagnostics: Yes (per channel)
• Protection Class: IP20 (in terminal assembly)
• Operating Temperature Range: -30 °C to +60 °C
• Dimensions (W × H × D): 15 mm × 73 mm × 58 mm
• Certifications: CE, cULus, ATEX, IECEx

Application Areas

• Safety-related automation requiring emergency shutdowns
• Industrial machines and process plants with safety functions
• Decentralized fail-safe control in ET 200SP environments
• Systems complying with international functional safety standards

Advantages

• Meets high safety requirements up to SIL 3 / PL e
• Compact module with high integration density
• Seamless integration with STEP 7 Safety Advanced and TIA Portal
• Channel diagnostics increase system reliability and reduce downtime
