Product Description: Siemens 6ES7135-6GB00-0BA1

The Siemens 6ES7135-6GB00-0BA1 is a digital output module from the SIMATIC S7-1200 series, providing 8 channels for controlling 24 V DC signals. This module is ideal for controlling relays, actuators, and other digital devices in industrial automation systems. Each output channel can handle up to 0.5 A, and it supports both sinking and sourcing output types (PNP or NPN). The module is easily integrated into the S7-1200 PLC system, offering reliable and efficient digital output control for a wide range of applications.

Key Features

• Digital Outputs: 8 channels for 24 V DC signals
• Output Type: Sinking or sourcing (PNP or NPN)
• Output Current: 0.5 A per channel
• Mounting: DIN rail within the SIMATIC S7-1200 system rack
• Configuration: Configured via TIA Portal or STEP 7
• Diagnostics: Integrated diagnostics for wire break and short circuit detection

Technical Specifications

• System Series: SIMATIC S7-1200
• Module Type: Digital Output Module (DO)
• Number of Outputs: 8
• Output Voltage: 24 V DC
• Output Current: 0.5 A per channel
• Output Type: Sinking or Sourcing (PNP or NPN)
• Power Supply: Via backplane bus
• Mounting: DIN rail
• Dimensions (W × H × D): Approx. 40 mm × 125 mm × 129 mm
• Operating Temperature Range: 0 °C to +60 °C
• Protection Class: IP20
• Certifications: CE, UL, cULus

Application Areas

• Control of digital devices such as relays, solenoids, and actuators
• Industrial control systems requiring high-density digital output
• Expansion of I/O capabilities for SIMATIC S7-1200 PLC systems
• Suitable for use in manufacturing, process control, and material handling systems

Advantages

• High-density 8-channel configuration for space-saving installations
• Reliable operation with diagnostic capabilities for easy troubleshooting
• Versatile compatibility with PNP and NPN devices
• Seamless integration with SIMATIC S7-1200 PLC via TIA Portal
