Industrial Communication | Siemens | 6ES7134-6JF00-0CA1 6ES7 134-6JF00-0CA1 ET 200SP Analog Input Module

Product Description: Siemens 6ES7134-6JF00-0CA1

The Siemens 6ES7134-6JF00-0CA1 is a 2-channel analog output module from the SIMATIC ET 200SP distributed I/O system. This standard module, designated as BA AO 2×U/I ST, provides two analog outputs that can be individually configured for either voltage (0–10 V) or current (0/4–20 mA) output. The module supports precise signal generation and is designed for compact and scalable automation solutions requiring analog control of actuators such as valves, dampers, and variable speed drives. This 15 mm-wide module is plugged into a compatible BaseUnit (BU type A0 or A1) and is configured via TIA Portal, with full support for diagnostics and parameterization.

Key Features

• 2 Analog Outputs: Individually configurable as voltage or current outputs
• High Signal Accuracy: Ensures stable and precise analog output for control applications
• Compact Design: 15 mm width for space- saving installation in control panels
• Hot-Swappable: Can be replaced during operation when used with a BU supporting hot swapping
• Standard Performance: Suitable for general-purpose analog signal control
• Channel Diagnostics: Includes open-loop monitoring and status reporting

Technical Specifications

• Product Type: Analog Output Module
• Part Number: 6ES7134-6JF00-0CA1
• Series: SIMATIC ET 200SP
• Module Type: BA AO 2×U/I ST
• Number of Outputs: 2 channels
• Output Types: 0–10 V, 0–20 mA, 4–20 mA
• Resolution: 12 bits
• Signal Accuracy: ±0.5% of full scale
• Channel Isolation: No isolation between channels
• Connection Type: Push-in terminals via BaseUnit (BU)
• Required BU Type: BU type A0 or A1
• Module Width: 15 mm
• Operating Voltage: Supplied via backplane bus
• Diagnostics: Open-circuit detection, parameter diagnostics
• Operating Temperature: -30°C to +60°C
• Protection Class: IP20
• Weight: Approx. 40 g

Application Areas

• Analog Actuator Control: Drives proportional valves, dampers, and analog actuators
• Process Automation: Provides control signals in dosing, mixing, and temperature regulation systems
• HVAC and Environmental Systems: Outputs analog control signals for fans, sensors, and regulators
• General Automation: Suitable for machinery requiring precision analog output values

Advantages

• Flexible Output Configuration: Supports both voltage and current modes
• High Channel Density: Two outputs in just 15 mm module width
• TIA Portal Integration: Simplifies configuration, diagnostics, and maintenance
• Safe and Reliable: Integrated diagnostics improve system uptime and reduce troubleshooting time
• Modular Expansion: Easily extends analog output capacity within ET 200SP systems
