Product Description: Siemens 6ES7134-6JD00-0CA1

The Siemens 6ES7134-6JD00-0CA1 is an analog input module from the SIMATIC ET 200SP series, designed to acquire voltage signals in distributed I/O systems. Classified as AI 2×U ST, this standard module provides 2 analog input channels for voltage measurement and is used with the ET 200SP BaseUnit and interface modules. It supports various voltage ranges and offers 16-bit resolution, making it suitable for precise analog signal acquisition in industrial automation environments. This module is part of the A0 module group and is compatible with BU type A0 BaseUnits. It features extensive diagnostics, compact dimensions, and is configured using the TIA Portal software environment.

Key Features

• 2 Voltage Input Channels: Measures standard voltage signals across configurable ranges.
• High Resolution: 16-bit A/D conversion ensures accurate data acquisition.
• Wide Input Range: Supports typical ranges such as ±10 V, 0–10 V, etc.
• Compact Design: Narrow profile fits into high-density I/O configurations.
• Advanced Diagnostics: Supports channel- specific diagnostics and status reporting.
• TIA Portal Integration: Easily configured and diagnosed using Siemens TIA Portal.

Technical Specifications

• Product Type: Analog Input Module
• Part Number: 6ES7134-6JD00-0CA1
• Series: SIMATIC ET 200SP
• Module Type: AI 2×U ST Standard
• Number of Channels: 2 analog inputs
• Input Signal Type: Voltage (e.g., 0–10 V, ±10 V)
• Resolution: 16-bit
• Module Group: A0
• BaseUnit Compatibility: BU type A0 (e.g., 6ES7193-4CA50-0AA0)
• Diagnostics: Channel-specific diagnostics
• Mounting: On ET 200SP BaseUnit (DIN rail)
• Operating Temperature: -30°C to +60°C
• Weight: Approx. 35 g

Application Areas

• Process Control: Accurate measurement of voltage signals from transmitters and sensors.
• Machine Automation: Used for monitoring analog values in packaging, printing, and textile machines.
• Energy Management: Captures analog input data for logging and optimization.
• Building Automation: Integrates with systems requiring high-precision voltage measurement.

Advantages

• Accurate Analog Acquisition: 16-bit precision supports critical control tasks.
• Compact and Scalable: Slim format ideal for modular system expansion.
• Reliable Signal Handling: Designed for industrial voltage input requirements.
• TIA Portal Ready: Simplifies configuration and reduces engineering time.
• Robust Operation: Suitable for industrial environments with extended temperature ranges.
