Product Description: Siemens 6ES7134-6GF00-0AA1

The Siemens 6ES7134-6GF00-0AA1 is a high-performance analog output module from the SIMATIC ET 200SP series, offering two analog output channels configurable for either voltage or current output. Designed for standard applications, it enables precise control of analog actuators such as valves, drives, or displays in decentralized automation systems. The module is engineered for seamless integration with the ET 200SP I/O platform, offering flexibility, compactness, and ease of use.

Key Features

• 2 analog output channels
• Configurable output types: voltage or current
• Voltage ranges: ±10 V, 0–10 V, 1–5 V, 0–5 V
• Current ranges: 0–20 mA, 4–20 mA
• High signal accuracy and resolution
• Integrated diagnostics and status indicators
• Standard (ST) module with base unit compatibility
• Hot-swappable for fast maintenance and replacement

Technical Specifications

• Part Number: 6ES7134-6GF00-0AA1
• Number of Outputs: 2
• Output Type: Voltage or Current (configurable)
• Resolution: 15 bits + sign
• Output Voltage Ranges: ±10 V, 0–10 V, 1–5 V, 0–5 V
• Output Current Ranges: 0–20 mA, 4–20 mA
• Output Load (Voltage): ≥10 kΩ
• Output Load (Current): ≤600 Ω
• Signal Conversion Time: <1 ms per channel
• Isolation: Between channels and backplane
• Mounting Method: Plug-in on ET 200SP BaseUnit (BU-type A0)
• Module Width: 15 mm
• Protection Class: IP20
• Operating Temperature: 0 °C to +60 °C
• Storage Temperature: –40 °C to +70 °C
• Certifications: CE, cULus, EAC

Application Areas

• Decentralized control systems with analog actuator requirements
• Process control systems requiring analog output for setpoint control
• Industrial applications in packaging, food, chemical, or HVAC
• Remote terminal units using ET 200SP for distributed I/O
• Compact machines and modular automation solutions

Advantages

• Dual-channel flexibility with voltage or current output per channel
• Accurate analog signal output for process control precision
• Easy module replacement via hot-swapping without system shutdown
• Space-saving design for high-density I/O applications
• Full integration with SIMATIC TIA Portal and ET 200SP system
