Industrial Communication | Siemens | 6ES7134-4JB00-0AB0 6ES7134-4JB00-0AB0 DP Electronics Module ET 200S

Product Description: Siemens 6ES7134-4JB00-0AB0 Analog Output Module

The Siemens 6ES7134-4JB00-0AB0 is an analog output module from the SIMATIC S7-1200 series, providing four channels for controlling 4–20 mA analog signals with 12-bit resolution. This module is ideal for applications requiring precise analog signal output for actuators, valves, and other control devices in industrial automation systems. The AO 4x20mA module is easily integrated into the S7-1200 PLC system and can be configured using the TIA Portal or STEP 7.

Key Features

• Analog Outputs: 4 channels for 20 mA current output
• Resolution: 12 bits (4096 values)
• Output Range: 4–20 mA (standard current loop)
• Output Current: 0–20 mA, 4–20 mA (selectable)
• Mounting: DIN rail mounting within the SIMATIC S7-1200 system rack
• Configuration: Configured via TIA Portal or STEP 7

Technical Specifications

• System Series: SIMATIC S7-1200
• Module Type: Analog Output Module (AO)
• Number of Outputs: 4
• Output Signal: 4–20 mA
• Resolution: 12 bits
• Output Current: 20 mA max per channel
• Power Supply: Via backplane bus
• Mounting: DIN rail
• Dimensions (W × H × D): Approx. 40 mm × 125 mm × 129 mm
• Operating Temperature Range: 0 °C to +60 °C
• Protection Class: IP20
• Certifications: CE, UL, cULus, RoHS

Application Areas

• Control of actuators and devices requiring precise current control
• Industrial automation systems for process control and monitoring
• Analog signal generation for temperature, pressure, or flow control
• Integration with SIMATIC S7-1200 PLC for modular, scalable automation

Advantages

• High-resolution 12-bit output for precise analog control
• Easy integration into the SIMATIC S7-1200 PLC system via TIA Portal
• Reliable control of 4–20 mA current loops for process control devices
• Versatile applications in industrial automation with selectable output ranges
