PLC | Siemens | 6ES7 307-1BA00-0AA0 6ES7307-1BA00-0AA0 Power Supply Module

Product Description: Siemens 6ES7307-1BA00-0AA0 (PS 307)

The Siemens 6ES7307-1BA00-0AA0 (PS 307) is a compact power supply module for the SIMATIC S7-300 automation system. It converts 120/230 V AC mains to a regulated 24 V DC output capable of supplying up to 5 A to the S7-300 backplane bus. With built-in protections and a slim 40 mm width, the PS 307 ensures reliable power delivery and space-efficient installation in control cabinets.

Key Features

• Input Voltage: 120/230 V AC (–15 % … +10 %), 47 … 63 Hz
• Output Voltage: Regulated 24 V DC
• Output Current: Up to 5 A to backplane bus
• Hold-Up Time: ≥ 20 ms at full load for brief mains interruptions
• Protections: Overload, short-circuit, and over-temperature with automatic recovery
• Diagnostics: Front-panel LED for “Power OK” indication
• Mounting: Snap-on to S7-300 DIN rail; occupies one module slot
• Protection Class: IP20 front; IP20 rear

Technical Specifications

• AC Input Voltage: 120/230 V AC (–15 % … +10 %)
• Input Frequency: 47 … 63 Hz
• DC Output Voltage: 24 V DC
• Rated Output Current: 5 A
• Power Loss at Rated Load: ≈ 12 W
• Hold-Up Time: ≥ 20 ms (at 5 A load)
• Protection Features: Overload, short-circuit, over-temperature
• Isolation: Input/output isolation per EN 61131-2
• Operating Temperature: 0 °C … +60 °C
• Storage Temperature: –40 °C … +85 °C
• Dimensions (W × H × D): 40 mm × 125 mm × 115 mm
• Weight: ≈ 0.3 kg

Application Areas

• Powering SIMATIC S7-300 CPUs and I/O modules in control cabinets
• Ensuring stable PLC operation during brief mains disturbances
• Use in manufacturing, process automation, and machine-building environments

Advantages

• Space-Saving: Slim 40 mm width conserves module slots in dense racks.
• Reliable Operation: Automatic protection and hold-up time guard against supply faults.
• Easy Diagnostics: “Power OK” LED quickly confirms module status.
• Simple Installation: Snap-on DIN-rail mounting and standard terminals streamline wiring.
