PLC | Siemens | 6ES7 217-1AG40-0XB0 SIMATIC S7-1200 CPU 1217C 6ES7217-1AG40-0XB0

Product Description: Siemens 6ES7217-1AG40-0XB0

The Siemens 6ES7217-1AG40-0XB0 is a digital output module from the SIMATIC S7-1200 series, providing 16 channels for controlling 24 V DC signals. This module is designed for use in industrial automation systems, enabling the connection of devices such as relays, actuators, and sensors. It supports both sinking and sourcing output types (PNP or NPN) and provides a reliable solution for controlling digital devices in various applications. The module is easily integrated into the S7-1200 PLC system for seamless communication and control.

Key Features

• Digital Outputs: 16 channels for 24 V DC signals
• Output Current: 0.5 A per channel
• Output Type: Sinking (NPN) or Sourcing (PNP)
• Mounting: DIN rail within the SIMATIC S7-1200 system rack
• Configuration: Configured via TIA Portal or STEP 7
• Diagnostics: Integrated diagnostic functions for wire break and short-circuit detection

Technical Specifications

• System Series: SIMATIC S7-1200
• Module Type: Digital Output Module (DO)
• Number of Outputs: 16
• Output Voltage: 24 V DC
• Output Current: 0.5 A per channel
• Output Type: Sinking (NPN) or Sourcing (PNP)
• Power Supply: Via backplane bus
• Mounting: DIN rail
• Dimensions (W × H × D): Approx. 40 mm × 125 mm × 129 mm
• Operating Temperature Range: 0 °C to +60 °C
• Protection Class: IP20
• Certifications: CE, UL, cULus

Application Areas

• Control of digital devices such as relays, actuators, and solenoids
• Industrial control and monitoring systems
• Integration with SIMATIC S7-1200 PLC for modular I/O expansion
• Suitable for use in manufacturing, process control, and material handling systems

Advantages

• High-density 16-channel configuration for space-saving installations
• Reliable operation with diagnostic capabilities for easy troubleshooting
• Versatile compatibility with PNP and NPN devices
• Seamless integration with SIMATIC S7-1200 PLC via TIA Portal
