Product Description: Siemens 6ES7138-4FA03-0AB0

The Siemens 6ES7138-4FA03-0AB0 is a digital output module from the SIMATIC S7-1200 series, providing 16 channels for 24 V DC digital signals. It is ideal for controlling digital devices such as relays, actuators, and solenoids in industrial automation systems. Each output channel can handle up to 0.5 A, and the module supports both sinking and sourcing output types (PNP or NPN). This module is easily integrated into the S7-1200 PLC system, providing reliable and efficient control of external devices.

Key Features

• Digital Outputs: 16 channels, 24 V DC
• Output Current: 0.5 A per channel
• Signal Type: Sinking or sourcing (PNP or NPN)
• Mounting: DIN rail within the SIMATIC S7-1200 system rack
• Configuration: Configured via TIA Portal or STEP 7
• Diagnostics: Integrated diagnostics for wire break and short circuit detection

Technical Specifications

• System Series: SIMATIC S7-1200
• Module Type: Digital Output Module (DO)
• Number of Outputs: 16
• Output Voltage: 24 V DC
• Output Current: 0.5 A per channel
• Output Type: Sinking or Sourcing (PNP or NPN)
• Power Supply: Via backplane bus
• Mounting: DIN rail
• Dimensions (W × H × D): Approx. 40 mm × 125 mm × 129 mm
• Operating Temperature Range: 0 °C to +60 °C
• Protection Class: IP20
• Certifications: CE, UL, cULus

Application Areas

• Control of digital actuators, relays, and other field devices
• Expansion of I/O capabilities in SIMATIC S7-1200 PLC systems
• Suitable for industrial automation applications in manufacturing, process control, and material handling systems
• High-density output module for space-efficient installations

Advantages

• High-density 16-channel configuration for compact installations
• Reliable control of 24 V DC digital signals with diagnostics for troubleshooting
• Versatile compatibility with PNP and NPN devices
• Easy configuration and integration using TIA Portal for enhanced productivity
