Product Description: Siemens 6ES7138-4FA02-0AB0

The Siemens 6ES7138-4FA02-0AB0 is a failsafe digital output module for the SIMATIC ET 200S distributed I/O system, designed specifically for safety- related applications. This F-DO (Failsafe Digital Output) module provides 4 independent 24 V DC outputs, each capable of switching up to 2 A. It supports safety functions up to SIL 3 (IEC 61508) and PL e (EN ISO 13849-1), making it suitable for use in emergency stop circuits, safe actuator control, and safety interlock systems. This module is part of Siemens' Safety Integrated system and is certified for use in PROFIsafe environments via PROFIBUS or PROFINET with appropriate interface modules. It is used together with the ET 200S BaseUnits and configured through the TIA Portal or STEP 7.

Key Features

• Failsafe Outputs: 4 isolated outputs with integrated safety logic.
• High Current Capacity: Each output supports up to 2 A at 24 V DC.
• Safety Integrity Level: Supports SIL 3 (IEC 61508) and PL e (EN ISO 13849-1).
• PROFIsafe Compatibility: Communicates via PROFIBUS/PROFINET with fail-safe CPUs.
• Electronic Protection: Short-circuit and overload protection included.
• Diagnostic Functions: Channel-level diagnostics and status monitoring.

Technical Specifications

• Product Type: Failsafe Digital Output Module
• Part Number: 6ES7138-4FA02-0AB0
• Series: SIMATIC ET 200S
• Module Type: F-DO 4×24 V DC/2 A HF
• Number of Outputs: 4
• Output Type: Electronically switched, 24 V DC
• Max. Output Current: 2 A per channel
• Safety Standards: SIL 3, PL e, Cat. 4
• Communication: PROFIsafe via ET 200S IM
• Diagnostics: Integrated channel diagnostics
• Mounting: On ET 200S BaseUnit (e.g. BU type E0/E1)
• Operating Temperature: 0°C to +60°C
• Protection Class: IP20 (when mounted in enclosure)
• Weight: Approx. 120 g

Application Areas

• Emergency Stop Circuits: Disconnects actuators or power in safety-critical events.
• Safety Interlocks: Ensures proper sequencing and safe system shutdown.
• Safe Actuator Control: Operates motors, solenoids, or valves under safety control.
• Machine and Plant Safety: Ideal for packaging, processing, and robotic safety systems.

Advantages

• Integrated Safety: Certified for use in fail-safe systems without external safety relays.
• Compact and Scalable: High channel density in a small footprint.
• Reliable Performance: Maintains output integrity under fault or short-circuit conditions.
• Seamless Configuration: Fully supported in TIA Portal with SIMATIC safety controllers.
• System Compatibility: Works within the ET 200S platform for unified safety and standard automation.
