Product Description: Siemens 6ES7131-4BD01-0AB0

The Siemens 6ES7131-4BD01-0AB0 is a digital input module from the SIMATIC ET 200S distributed I/O system. Classified as DI 8×24 V DC ST, it provides 8 digital inputs for 24 V DC signals. Designed in a compact 15 mm-wide electronics module form factor, it enables high-density digital input expansion for ET 200S stations. This standard module is optimized for use in automation systems requiring fast and reliable acquisition of binary signals such as sensors, switches, and pushbuttons. The module supports diagnostics functions, including wire break detection (when used with the appropriate terminal modules), and is fully configurable via the Siemens TIA Portal or STEP 7.

Key Features

• 8 Digital Inputs: For acquiring 24 V DC binary signals.
• Compact Design: 15 mm wide, suitable for high-density installations.
• Standard Module: Cost-effective digital input expansion for ET 200S.
• Fast Signal Acquisition: Designed for high-speed input detection in automation systems.
• Diagnostic Capabilities: Supports diagnostics such as short-circuit or wire break (with appropriate terminals).
• Modular Configuration: Easily replaced or expanded without rewiring.

Technical Specifications

• Product Type: Digital Input Module
• Part Number: 6ES7131-4BD01-0AB0
• Series: SIMATIC ET 200S
• Module Type: DI 8×24 V DC ST
• Number of Inputs: 8 digital inputs
• Input Voltage: 24 V DC
• Input Delay: Typically 0.5 ms
• Module Width: 15 mm
• Diagnostics: Wire break, short-circuit (with TM-E terminal)
• Mounting: On BaseUnits of ET 200S
• Operating Temperature: 0°C to +60°C
• Weight: Approx. 40 g

Application Areas

• Sensor Signal Acquisition: Captures binary signals from proximity sensors, switches, and contact inputs.
• Distributed Control Systems: Used in decentralized I/O configurations in ET 200S systems.
• Panel Automation: Ideal for compact control panel applications requiring high I/O density.
• General Industrial Automation: Suitable for use in packaging machines, conveyors, and assembly lines.

Advantages

• High-Density Inputs: Offers 8 inputs in a narrow 15 mm format.
• Efficient Expansion: Easily extends I/O capabilities of ET 200S systems.
• Simple Installation: Plug-in module design enables quick replacement or upgrade.
• Flexible Diagnostics: Helps identify wiring or signal faults when used with diagnostic terminals.
• Seamless Integration: Configured and managed within TIA Portal and STEP 7 environments.
