PLC | Siemens | 6ED1055-1MA00-0BA2 6ED1 055-1MA00-0BA2 LOGO DM8 24R expansion

Product Description: Siemens 6ED1055-1MA00-0BA2

The Siemens 6ED1055-1MA00-0BA2 is a digital expansion module from the LOGO! 8 series, designed to extend the input/output capacity of LOGO! basic modules. It features 8 digital inputs (24 V DC) and 8 relay outputs, making it suitable for switching loads such as contactors, lights, and valves. Ideal for compact automation tasks, the DM16 24R module allows easy integration into building automation, small machinery control, and energy management systems.

Key Features

• Digital Inputs: 8 channels, 24 V DC
• Digital Outputs: 8 relay outputs (NO contact)
• Output Switching Capacity: 10 A resistive load, 3 A inductive load
• Wiring: Spring-loaded terminals for fast installation
• Mounting: DIN rail installation
• Compatibility: LOGO! 8 and compatible base modules
• Configuration: Via LOGO! Soft Comfort software

Technical Specifications

• System Series: LOGO! 8
• Module Type: Digital Expansion Module
• Number of Digital Inputs: 8 (24 V DC)
• Number of Digital Outputs: 8 (Relay, NO contacts)
• Output Current per Channel: Max. 10 A resistive, 3 A inductive
• Switching Voltage: 5–30 V DC / 5–250 V AC
• Power Supply Voltage: 24 V DC
• Mounting Type: DIN rail
• Dimensions (W × H × D): 126 mm × 90 mm × 60 mm
• Operating Temperature Range: 0 °C to +55 °C
• Protection Class: IP20
• Certifications: CE, cULus, EAC

Application Areas

• Expansion of I/O in LOGO!-based automation systems
• Small machine control in OEM equipment
• Lighting and HVAC control in building automation
• Control of electromechanical devices via relay outputs

Advantages

• High I/O density in a compact form factor
• Reliable relay outputs for direct load switching
• Seamless integration with LOGO! logic modules
• Easy configuration and installation for fast deployment
