Product Description: Siemens 6ED1055-1FB00-0BA2

The Siemens 6ED1055-1FB00-0BA2 is a 7-inch HMI (Human Machine Interface) panel from the SIMATIC HMI series, specifically the KTP 700 Basic model. It is designed to provide operators with an intuitive interface for controlling and monitoring industrial machines and processes. Featuring a high-resolution TFT color display and a touch-screen interface, the panel is perfect for applications in factory automation, process control, and machine control systems. The HMI panel supports communication with Siemens PLCs using PROFINET, enabling seamless data exchange and integration into industrial networks.

Key Features

• Display Size: 7-inch TFT color touchscreen for clear and easy visualization of process data.
• Display Type: High-resolution TFT display offering sharp, clear visual feedback for operators.
• User Interface: Touchscreen interface for intuitive control of machinery and system parameters.
• Communication Protocols: PROFINET for seamless communication with Siemens PLCs and other industrial control systems.
• Programming: Configured using Siemens TIA Portal or WinCC flexible software, allowing for straightforward setup and integration.
• Mounting: Panel mount for easy installation in control cabinets or machine enclosures.
• Operating Temperature Range: Designed for industrial environments with an operating temperature range from 0°C to +50°C.
• Diagnostic Features: Built-in diagnostics allow for efficient monitoring of the system’s status and quick identification of issues.

Technical Specifications

• Product Type: Human Machine Interface (HMI)
• Part Number: 6ED1055-1FB00-0BA2
• Display Size: 7-inch
• Display Type: TFT, high-resolution
• Touch Interface: Yes, touchscreen interface
• Communication Protocols: PROFINET, Industrial Ethernet
• Operating Temperature Range: 0°C to +50°C
• Mounting: Panel mount
• Dimensions (W x H x D): 194 mm x 150 mm x 43 mm
• Weight: Approx. 0.6 kg

Application Areas

• Factory Automation: Ideal for controlling and monitoring machines, conveyors, and production lines in manufacturing environments.
• Process Control: Suitable for industries such as food processing, chemical, and pharmaceuticals, where real-time monitoring and control are required.
• Machine Control: Provides an interface for controlling machinery, allowing operators to easily adjust settings and parameters.
• Building Automation: Can be used for controlling building systems such as HVAC, lighting, and security systems in a building automation network.

Advantages

• High-Resolution Display: The TFT display provides clear, detailed visualization of system data, making it easier for operators to monitor and control processes.
• Compact Design: The 7-inch size strikes a balance between usability and space-saving, making it ideal for small to medium-sized control panels.
• Seamless Integration: Supports PROFINET for easy integration with Siemens PLCs and other devices, streamlining data communication within the automation system.
• Reliable Diagnostics: Built-in diagnostic functions help identify issues quickly, improving system reliability and reducing downtime.
